Drive Board Overview: The Siemens G120XA Inverter Drive Board (Model: A5E43506563) is an original genuine core component independently developed and manufactured by Siemens official factory, dedicated to matching Siemens G120XA series inverters. It adopts Siemens advanced digital control technology, high-precision industrial-grade electronic components and optimized circuit design, undergoing strict factory precision calibration, full-process quality inspection and long-term stability testing to ensure 100% brand-new original quality without any manual modification or secondary processing. Fully compliant with Siemens global product standards, international industrial control norms and relevant international certifications, it features high control precision, strong anti-interference ability, stable operation performance and perfect compatibility. As the core control unit of G120XA inverters, it is responsible for signal processing, frequency conversion control and drive output, widely applied in industrial transmission systems such as machinery manufacturing, water supply and drainage, fan and pump, metallurgy, chemical industry, textile and intelligent equipment. It is perfectly compatible with Siemens G120XA inverter mainframes, PLCs and industrial sensors, supporting seamless integration into existing industrial control networks and stable operation in harsh industrial environments.
|
Parameter
|
Specification (A5E43506563)
|
Unit
|
Factory Notes (Original Description)
|
|
Brand & Origin
|
Siemens, Original Factory, Brand New Genuine Product
|
-
|
100% brand-new original drive board produced by Siemens official factory, manufactured in strict accordance with Siemens global quality management standards, ensuring consistent performance and long service life.
|
|
Product Model
|
A5E43506563
|
-
|
Original factory model, unchanged; dedicated for Siemens G120XA series inverters, standardized design for easy on-site replacement, installation and parameter configuration.
|
|
Product Type
|
Inverter Drive Board, Digital Control, Core Control Component
|
-
|
Industrial-grade digital control drive board, as the core component of Siemens G120XA inverters, responsible for signal processing, frequency conversion control and drive output, ensuring stable operation of the inverter.
|
|
Rated Supply Voltage
|
24 V DC ±10% (Control Circuit); 380-480 V AC (Main Circuit Interface)
|
V DC/V AC
|
Control circuit: 24V DC ±10% wide voltage tolerance; main circuit interface: 380-480V AC, adapting to different industrial power supply environments.
|
|
Rated Control Current
|
0.8 A (Continuous); 2.5 A (Peak, 2 Seconds)
|
A
|
Continuous control current 0.8A, peak control current 2.5A (sustained for 2 seconds), strong load-bearing capacity, ensuring stable drive of inverter main circuit components.
|
|
Control Mode
|
V/F Control, Sensorless Vector Control, Vector Control (Optional)
|
-
|
Supports three flexible control modes, which can be switched according to actual application needs of G120XA inverters, realizing precise speed and torque control of motors.
|
|
Frequency Control Range
|
0.01-600 Hz (Precision Control)
|
Hz
|
High-precision frequency control range, minimum control frequency 0.01Hz, ensuring precise speed regulation of motors in industrial transmission systems.
|
|
Frequency Control Precision
|
±0.01% (of Rated Frequency)
|
%
|
High frequency control precision, up to ±0.01% of rated frequency, meeting the requirements of high-precision industrial transmission control scenarios.
|
|
Communication Interface
|
PROFINET, Modbus RTU (Standard); PROFIBUS, EtherNet/IP (Optional)
|
-
|
Standard PROFINET and Modbus RTU interfaces, optional PROFIBUS and EtherNet/IP interfaces, supporting seamless connection with Siemens PLCs and industrial control systems.
|
|
Operating Temperature Range
|
-10 ~ 60 °C (Operating); -40 ~ 85 °C (Storage)
|
°C
|
Wide operating and storage temperature range, with built-in heat dissipation design, avoiding overheating failure in high-temperature industrial environments.
|
|
Relative Humidity
|
5 ~ 95% (Non-condensing), No Dew Formation
|
%
|
Strong humidity resistance, effectively protecting internal circuit components from moisture damage, suitable for humid industrial environments such as chemical plants and water treatment plants.
|
|
Protection Level
|
IP20 (Board Level); IP54 (With Protective Cover)
|
-
|
Board level IP20 protection, optional protective cover with IP54 protection level, preventing dust and water jets from entering, extending the service life of the drive board.
|
|
Physical Dimensions (W×H×D)
|
180 × 120 × 30 (±1) mm (Standard Version)
|
mm
|
Compact structural design, matching the installation space of Siemens G120XA inverter mainframes, easy to assemble and disassemble on site.
|
|
Weight
|
Approx. 0.35 ~ 0.4 kg (Standard Version)
|
kg
|
Lightweight and durable, easy to carry and transport during on-site maintenance and replacement, without additional load on the inverter mainframe.
|
|
Protection Functions
|
Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Earth Fault, Signal Interference Protection
|
-
|
Integrated multiple comprehensive protection functions, quickly responding to abnormal working conditions, protecting the drive board, inverter mainframe and motor from damage.
|
|
Certifications & Compliance
|
ISO 9001, CE, UL, CSA, IEC 61800-5-1
|
-
|
Complies with international quality management systems, industrial safety standards and drive board technical norms, meeting global industrial project application requirements.
|
|
Warranty Period
|
1 Year (Original Factory Warranty)
|
Year
|
Provides 1-year original factory warranty, covering manufacturing defects and performance failures under normal use; Siemens professional after-sales team provides technical support.
|
|
Compatibility
|
Siemens G120XA Series Inverters, Siemens PLCs, Industrial Sensors
|
-
|
Perfectly compatible with Siemens G120XA inverter mainframes, Siemens PLCs and various industrial sensors, easy to integrate into existing industrial control systems.
|
