1 PCS used ADLINK DAQe-2206(G)-0150 Board #LYQ007
1 PCS used ADLINK DAQe-2206(G)-0150 Board #LYQ007
1 PCS used ADLINK DAQe-2206(G)-0150 Board #LYQ007
Original Factory Precision Parameters (Model: ADLINK DAQe-2206(G)-0150 Board)
|
Parameter Category
|
Parameter Name
|
DAQe-2206(G)-0150 Specification
|
|
Basic Information
|
Product Model
|
DAQe-2206(G)-0150; ADLINK Genuine Original DAQ Board, 100% unused and unrefurbished genuine parts
|
|
Manufacturer Standard
|
Manufactured by ADLINK; Compliant with ISO 9001, CE, RoHS, FCC, UL Standards; Conforms to ADLINK Internal Technical Norms
|
|
|
Product Application
|
Industrial Data Acquisition, Industrial Automation, Equipment Monitoring, High-Precision Signal Acquisition, Power Quality Analysis Scenarios
|
|
|
Core Performance & Interface Parameters
|
Interface Type
|
PCI Express x1 Gen 2, Compatible with PCIe x1/x4/x8/x16 Slots, Plug-and-Play, Hot-Swappable Supported
|
|
Analog Input Channels
|
8 Single-Ended / 4 Differential Channels, 16-Bit Resolution, High-Precision ADC Chip
|
|
|
Sampling Rate
|
Up to 150 kS/s (Single Channel), 100 kS/s (Multi-Channel), Continuous Sampling and Burst Sampling Supported
|
|
|
Input Range
|
Configurable: ±10V, ±5V, ±2.5V, 0~10V, 0~5V; Bipolar/Unipolar Selectable, Automatic Range Calibration Supported
|
|
|
Input Impedance
|
≥10 GΩ (Voltage Input), Low Leakage Current (≤1 nA), Ensuring Sampling Accuracy and Signal Integrity
|
|
|
Digital I/O Channels
|
16 Channels (8 Input / 8 Output), TTL Level, Configurable Input/Output Mode, Programmable Interrupt Trigger
|
|
|
Precision & Timing Parameters
|
Integral Nonlinearity (INL)
|
±0.01% FSR (Full Scale Range), High Sampling Precision, Meeting Industrial Grade High-Precision Requirements
|
|
Differential Nonlinearity (DNL)
|
±0.005% FSR, No Missing Codes, Ensuring Data Integrity and Sampling Reliability
|
|
|
Signal-to-Noise Ratio (SNR)
|
≥85 dB @ 1 kS/s, Low Noise Design, Built-in Low-Pass Filter, Clear Signal Acquisition
|
|
|
Trigger Mode
|
Software Trigger, Hardware Trigger, External Trigger, Edge Trigger (Rising/Falling), Level Trigger, Programmable Trigger Conditions
|
|
|
Timer/Counter
|
2 Channels, 32-Bit, Configurable for Timing, Counting and Pulse Generation, Frequency Measurement Supported
|
|
|
Power Quality Analysis
|
Harmonic Analysis Range: 1 - 63rd Harmonic; Voltage, Current, Power and Active Energy Error: ≤0.1%; Grid Frequency Error: ≤0.01Hz
|
|
|
Electrical & Protection Parameters
|
Input Voltage Protection
|
Overvoltage Protection: ±15V (Max); Anti-Surge Protection, Overcurrent Protection, Protecting Internal Circuits from Damage
|
|
Power Supply
|
Powered by PCIe Slot, DC 12V ±10%, Typical Power Consumption: ≤8W, Low Power Design for Energy Saving
|
|
|
Anti-Interference Performance
|
Built-in EMI Filter, Complies with EN 55022 Class A, Resisting Industrial Electromagnetic Interference, Stable Operation in Harsh Environments
|
|
|
ESD Protection
|
±8kV (Contact), ±15kV (Air), Effectively Protecting the Board from Static Damage, Extending Service Life
|
|
|
Environmental & Structural Parameters
|
Operating Temperature
|
-40°C ~ 85°C, Wide Temperature Range, Adapting to Various Industrial Harsh Environments
|
|
Storage Temperature
|
-55°C ~ 100°C, Stable Storage Performance, No Performance Degradation After Long-Term Storage
|
|
|
Relative Humidity
|
5% ~ 95% (Non-Condensing), Resisting Humid Industrial Environments, No Short Circuit Risk
|
|
|
Structure Material
|
Industrial-Grade PCB Board, Anti-Corrosion, Anti-Oxidation, High Mechanical Strength, Dust-Proof Design
|
|
|
Software & Compatibility
|
Operating System Support
|
Windows 10/11 Pro (64-bit), Windows Server, Linux Ubuntu 22.04 LTS, Compatible with 64-bit Operating Systems
|
|
Software Support
|
ADLINK DAQNavi SDK, LabVIEW Compatible, MATLAB Compatible, Easy for Secondary Development and System Integration
|
