Part Number: 80190-220-01-R (Model: ABB Industrial Drive Control Board)
Alternate P/N: N/A (Original ABB Component, Compatible with ABB Spare Parts System)
Brand: ABB Industrial Automation
Product Category: Industrial Drive Control Board (For Low-Voltage AC Inverters)
Product Series: ABB Inverter Drive Board (Compatible with ABB ACS580/ACS880 Series Low-Voltage AC Drives)
Core Application: Dedicated to ABB ACS580/ACS880 series low-voltage AC drives, widely applied in power generation, oil & gas, chemical engineering, metallurgy, water treatment, and general machinery industries. Serves as the core control unit of the inverter drive system, responsible for motor speed regulation, torque control, power conversion control, real-time state monitoring, and seamless communication with upper-level controllers. Supports both variable torque and constant torque applications such as pumps, fans, conveyors, mixers, and precision process control equipment, ensuring stable and efficient operation of the drive system.
Core Features: Integrated Direct Torque Control (DTC) algorithm for high-precision motor control; support for multiple motor types (induction motor, permanent magnet motor); built-in multi-protocol communication interfaces; industrial-grade coated circuit board design for harsh environment resistance; real-time fault diagnosis and alarm function; compatibility with ABB Drive Composer configuration software; modular structure for easy maintenance and hot-swap capability; compliance with SIL3 safety standards, integrated Safe Torque Off (STO) function; built-in EMC filter for reduced electromagnetic interference.
2. Electrical Specifications
Operating Voltage: +5V DC (±5%), +12V DC (±10%), +24V DC (±10%), compliant with ABB inverter power supply standards
Power Consumption: ≤30W (typical); ≤40W (maximum, full load with all peripherals connected)
Signal Interfaces: Motor Control Interface: 3-phase output (for inverter module driving); Encoder Interface: 1 channel (incremental encoder, up to 1MHz); Communication Interfaces: 1 × RS-485 (Modbus RTU), 1 × Ethernet (RJ45, PROFINET compatible), 1 × USB (configuration port); Digital I/O: 12 input/8 output (TTL level, for sensor and actuator control); Analog I/O: 4 input (0-10V DC/4-20mA), 2 output (0-10V DC/4-20mA); Safety Interface: STO signal input (2-channel, SIL3 compliant)
Control Precision: Speed Regulation Precision: ±0.1% of rated speed (with encoder feedback); Torque Control Precision: ±5% of rated torque; Frequency Control Range: 0.01Hz ~ 500Hz; Motor Speed Resolution: 0.01rpm
Communication & Response: Ethernet Data Transfer Rate: 10/100Mbps; Control Loop Update Rate: 25μs (DTC mode); Signal Processing Delay: ≤1ms; Supported Protocols: Modbus RTU, PROFINET, Ethernet/IP (compatible), ABB proprietary drive protocol; Supports remote monitoring and parameter configuration via Drive Composer
Control Functions: Direct Torque Control (DTC); V/F control (optional); Speed/torque/position control modes; Automatic motor parameter identification; Energy optimization mode; Process PID control; Recipe management (up to 500 recipes); Data logging and traceability; Automatic fault reset and recovery
Protection Functions: Overvoltage/undervoltage protection (input/output); Overcurrent protection; Short-circuit protection (motor side); Overheating protection (board and motor); Motor overload protection; ESD protection (±8kV contact, ±15kV air) per IEC 61000-4-2; Surge protection per IEC 61000-4-5; Phase loss protection; Ground fault protection; STO safety protection (SIL3 compliant)
