1 PCS USED Lambda Alpha Power Supply CA1500 24K 22N 22N 48J #LYQ007
1 PCS USED Lambda Alpha Power Supply CA1500 24K 22N 22N 48J #LYQ007
1 PCS USED Lambda Alpha Power Supply CA1500 24K 22N 22N 48J #LYQ007
|
Parameter Category
|
Parameter Name
|
Original Factory Precision Specification
|
|
Basic Information
|
Product Model
|
CA1500 24K 22N 22N 48J; TDK-Lambda Alpha Series Multi-Output Power Supply (Genuine Original Factory Code); 100% unused and unrefurbished genuine parts, consistent with TDK-Lambda official model coding standards; Model Interpretation: CA1500 (Series & Power Grade), 24K/22N/22N/48J (Four Output Channels with Corresponding Specifications), belonging to high-efficiency industrial-grade multi-output power supply.
|
|
Manufacturer Standard
|
Manufactured by TDK-Lambda Corporation (Genuine Original Factory); Compliant with ISO 9001 Quality Certification, CE, RoHS, UL, IEC 60950-1, IEC 61558-2-1 Power Supply Safety Standards; Conforms to TDK-Lambda Internal Technical Standard and Industrial Multi-Output Power Supply Manufacturing Norms.
|
|
|
Electrical Parameters
|
Input Voltage
|
Universal AC Input: 85V ~ 264V AC; Frequency: 47Hz ~ 63Hz; Input Voltage Fluctuation: ±10%; Built-in inrush current suppression circuit and input filter, effectively reducing impact on grid and peripheral equipment, with power factor correction (PFC) function.
|
|
Input Current
|
Max Input Current: 12A (115V AC), 6A (230V AC); Rated Input Current: 8A (115V AC), 4A (230V AC); Consistent with original factory calibrated values, ensuring stable power input and low energy consumption.
|
|
|
Total Output Power
|
1500W (Rated Total Output Power); Peak Output Power: 1800W (Duration ≤ 30s); Output Power Tolerance: ±5%, strictly calibrated by the original factory to ensure stable power supply for multi-channel loads.
|
|
|
Output Channel 1 (24K)
|
Output Voltage: 24V DC (Precision: ±1%); Rated Output Current: 25A; Max Output Current: 30A (Duration ≤ 10s); Ripple & Noise: ≤ 50mVp-p (20MHz Bandwidth); Line Regulation: ≤ 0.5%, Load Regulation: ≤ 1%.
|
|
|
Output Channel 2 (22N)
|
Output Voltage: 22V DC (Precision: ±1%); Rated Output Current: 20A; Max Output Current: 25A (Duration ≤ 10s); Ripple & Noise: ≤ 50mVp-p (20MHz Bandwidth); Line Regulation: ≤ 0.5%, Load Regulation: ≤ 1%.
|
|
|
Output Channel 3 (22N)
|
Consistent with Output Channel 2 (22N): Output Voltage 22V DC (±1% Precision), Rated Output Current 20A, Max Output Current 25A (≤10s), Ripple & Noise ≤50mVp-p, Line & Load Regulation ≤1%.
|
|
|
Output Channel 4 (48J)
|
Output Voltage: 48V DC (Precision: ±1%); Rated Output Current: 12.5A; Max Output Current: 15A (Duration ≤ 10s); Ripple & Noise: ≤ 100mVp-p (20MHz Bandwidth); Line Regulation: ≤ 0.5%, Load Regulation: ≤ 1%.
|
|
|
Efficiency
|
Typical Efficiency: 92% (Full Load, 230V AC Input); Minimum Efficiency: 88% (Light Load, 85V AC Input); High-efficiency design, reducing energy loss and heat generation, meeting global energy-saving standards.
|
|
|
Mechanical Parameters
|
Dimensions (H×W×D)
|
Compact industrial design; Specific dimensions: 127mm × 305mm × 406mm (Original Factory Calibrated); Tolerance: ±0.5mm; Compatible with standard 19-inch rack installation or wall-mounted installation, saving installation space.
|
|
Weight
|
12.5kg (Net Weight); 14.0kg (Gross Weight); Original factory precision weighing, consistent with the weight standard of genuine TDK-Lambda Alpha series multi-output power supplies, with stable mechanical structure.
|
|
|
Structure & Material
|
Enclosure Material: High-strength cold-rolled steel; Surface Treatment: Anti-corrosion electrostatic spraying; Protection Structure: IP30 (Closed Type); Main circuit and control circuit adopt high-quality screw-type terminal blocks, easy to wire and maintain, with good heat dissipation performance.
|
|
|
Interface & Control
|
Control Interface
|
Equipped with power on/off control terminal, remote sense terminal (for each output channel), and output voltage adjustment terminal; Supports remote on/off control and fine-tuning of output voltage, adapting to different application requirements.
|
|
Monitoring Function
|
Built-in LED status indicator (Power On, Output Normal, Fault); Optional LCD display for real-time monitoring of input voltage, each channel's output voltage, output current and total power; Supports fault signal feedback (dry contact output).
|
|
|
Communication Function
|
Standard RS485 communication interface; Supports Modbus RTU protocol; Enables real-time data exchange and remote control with industrial automation systems, facilitating centralized monitoring of multiple power supplies.
|
|
|
Environmental & Safety
|
Operating Temperature
|
Operating Temperature Range: -10℃ ~ +50℃; Storage Temperature Range: -20℃ ~ +85℃; No condensation or frost; Built-in temperature control fan, adjusting speed according to temperature, adapting to harsh industrial workshop environments.
|
|
Relative Humidity
|
20% ~ 90% (Non-condensing); Moisture-proof and mold-proof design, with good insulation performance, ensuring stable operation in high-humidity environments.
|
|
|
Protection Functions
|
Overload Protection (110% ~ 150% rated load, automatic shutdown or current limiting), over-voltage, under-voltage, short-circuit, over-temperature, reverse polarity protection; Built-in ESD anti-static protection (±15kV contact, ±25kV air), ensuring safe operation of power supply and loads.
|
|
|
Application & Compatibility
|
Applicable Loads
|
Suitable for multi-load industrial equipment, including industrial automation control systems, precision instruments, electronic testing equipment, medical equipment (non-life-support), and communication equipment; Supports simultaneous stable power supply for four different specifications of loads.
|
|
Applicable Fields
|
Widely used in industrial manufacturing, electronic processing, laboratory testing, medical equipment, communication base stations and other fields, realizing efficient, stable and reliable multi-channel power supply, improving equipment operation efficiency.
|
|
|
Factory Standard
|
Production Process
|
Adopts SMT (Surface Mount Technology) + precision assembly process; Closed-circuit anti-interference design, effectively reducing electromagnetic interference (EMI) and radio frequency interference (RFI), complying with global EMI/RFI standards.
|
|
Quality Assurance
|
100% Genuine TDK-Lambda Original Factory Parts; Factory tested and calibrated before delivery, 100% full-load aging test; Original factory warranty: 3 years; Unused, unsealed original packaging (optional), with complete factory certification documents.
|
