Minimum Supply Voltage    10    VDC    Wide voltage adaptation, anti-fluctuation
Nominal Supply Voltage    50    VDC    Optimal working voltage, max efficiency
Maximum Supply Voltage    59    VDC    Overvoltage protection threshold: 65VDC
Auxiliary Supply Voltage    24±20%    VDC    Independent control power, bus power-off communication reserved
Auxiliary Power Consumption    ≤8    VA    Ultra-low standby power consumption
Max Continuous Power Output    250    W    5A@50VDC, rated working condition
Peak Power Output    500    W    10A@50VDC, 10s duration, overload drive
Efficiency (@Rated Power)    ＞97    %    No rectifier loss, DC bus direct power
Max Output Voltage    ＞97% of DC Bus    V    22kHz PWM frequency, no step voltage drop

Continuous Output Current (Sinusoidal/DC)    5    A (RMS)    Precision current linearity 2000:1
Sinusoidal RMS Current Limit (Ic)    3.5    A    Continuous working current limit
Peak Current Limit    10 (2×Ic) / 20 (instant)    A    10s continuous peak / ms-level instant peak
Current Loop Bandwidth    ＜2.5    kHz    Ultra-fast current response, torque ripple suppression
Current Sampling Rate    11 (Max 16)    kHz    90μs sampling cycle, real-time current control
PWM Switching Frequency    22±5%    kHz    Programmable, advanced unipolar PWM mode
PWM Switching Method    Advanced Unipolar PWM    -    Low switching loss, ultra-low EMI noise
