1 PCS used Copley Controls ACM-180-09 Accelnet Module #LYQ007
1 PCS used Copley Controls ACM-180-09 Accelnet Module #LYQ007
| Parameter | Value |
|---|---|
| Model | ACM-180-09 |
| Input Voltage | +20 to +180 Vdc |
| Continuous Current (Ic) | 3 Adc (2.1 Arms) |
| Peak Current (Ip) | 9 Adc (6.34 Arms) |
| Peak Time | 1 sec |
| Continuous Output Power | 0.8 kW |
| Peak Output Power | 2.7 kW |
| Control Modes | Indexer, Point-to-Point, PVT, Camming, Gearing, Position, Velocity, Torque |
| Command Interface | CANopen, RS-232, ±10 Vdc analog, PWM, Stepper (Pls/Dir, CW/CCW), Master encoder |
| Communication | CANopen (CiA-301 V4.2.0, DSP402), RS-232 (9,600–115,200 Baud) |
| Feedback | Digital quadrature encoder, Hall sensors, Resolver (-R option) |
| Digital I/O | 10 configurable inputs, 2 programmable outputs |
| Protection | Overvoltage, I²T current limit, Over-temperature, Short-circuit |
| Dimensions (mm) | 102 × 69 × 25 |
| Operating Temp | 0 to 70 °C |
| Humidity | 0–95% non-condensing |
| Vibration | 2 g peak, 10–500 Hz (IEC 60068-2-6) |
| Shock | 10 g, 10 ms half-sine (IEC 60068-2-27) |
| Certifications | CE (EMC, LVD), UL 61010-1, RoHS |
| Mounting | PCB-mount, 6-32 screws (8–10 lb-in torque) |
