Reading Capability    1D: Code 39, Code 128, EAN-8/13, UPC-A/E, Interleaved 2 of 5, etc.
2D: QR Code, Data Matrix, PDF417, Aztec Code    Supports damaged, distorted, or low-contrast barcodes (industrial-grade decoding algorithm)
Resolution    1.2 MP (1280 × 960 pixels)    High imaging resolution for small barcode reading (min. 3 mil barcode density)
Reading Speed    Up to 100 barcodes per second    High-speed decoding for fast-moving objects on production lines
Working Distance    50 mm ~ 500 mm (varies by barcode size and lens type)    Flexible scanning range for different installation scenarios
Field of View (FOV)    60° (horizontal) × 45° (vertical)    Wide FOV to cover large target areas
Illumination System    White LED (visible light) + Red LED (aiming light)    Uniform illumination, no glare; aiming light for quick installation alignment
Decoding Algorithm    Datalogic StarDot™ & Green Spot™ Technology    High first-pass read rate (FPRR); Green Spot indicator confirms successful reading

Power Supply    12 ~ 24 VDC ±10%    Wide voltage range, suitable for industrial power systems
Power Consumption    Typical: 3.5 W; Max: 5 W    Low power consumption, energy-saving for 24/7 operation
Current Draw    Max: 210 mA (at 24 VDC)    Stable power demand, no voltage sag under load
Electrical Isolation    Input/Output: 1500 V AC (1 min)    Prevents signal interference and ground loop issues
Protection Functions    Overvoltage, reverse polarity, short-circuit protection    Industrial-grade fault tolerance, no damage from miswiring

1  .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
 Including : frequency converter, servo driver, servo motor,   data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial   computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
 3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please    contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
