Valve Body Material    Ductile Iron (GJS-400-15)    -    High strength, corrosion resistance for industrial environments
Spool Material    Hardened Stainless Steel    -    Wear resistance, long service life
Seal Material    Nitrile (NBR)    -    Compatible with mineral oil, anti-aging
Mounting Standard    ISO 4401-03-05-0-05    -    Standard flange mounting, interchangeable with similar valves
Overall Dimensions (L×W×H)    220 × 110 × 180    mm    Approximate dimensions, including solenoids
Net Weight    ≈ 12    kg    Approximate weight, without accessories
Protection Grade    IP65 (Electrical Connector)    -    Dust-proof and water-jet proof, suitable for harsh industrial sites

Solenoid Type    Proportional Force Motor    -    Integrated LVDT position feedback for closed-loop control
Coil Voltage    24    VDC    Rated voltage, ±10% tolerance
Nominal Coil Current    0.8    A    At rated voltage, no load
Coil Power Consumption    19.2    W    Per solenoid coil
Control Signal Input    0 ~ 10    VDC    Analog command signal, proportional to flow output
Feedback Signal Output    0 ~ 5    VDC    LVDT position feedback, proportional to spool stroke
Response Time (Step Input)    ≤ 30    ms    0-100% spool stroke, at 210 bar supply pressure
Hysteresis    ≤ 3    %    Full stroke range, repeatable operation
Repeatability    ≤ 1    %    Full stroke range, under constant temperature & pressure
Electrical Connection    DIN 43650 A Connector    -    IP65 protection grade, industrial standard connection

 1  .Our company specializes in automation industrial control accessories. We have more than 100,000 products.

 Including : frequency converter, servo driver, servo motor,   data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial   computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
 3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please    contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
