1 PCS used MKS 275330-GR Mini-Convectron® Vacuum Gauge #LYQ007
1 PCS used MKS 275330-GR Mini-Convectron® Vacuum Gauge #LYQ007
| Parameter | Specification |
|---|---|
| Part Number | 275330-GRMKS |
| Product Type | Mini-Convectron® Vacuum Pressure Transducer |
| Measurement Range (N₂ / Air) | 1 x 10⁻⁴ Torr to 1000 TorrMKS |
| 1 x 10⁻⁴ mbar to 1333 mbarMKS | |
| 1 x 10⁻² Pa to 1.33 x 10⁵ PaMKS | |
| Analog Output | Non-linear: 0.375 – 5.659 VDC (0–1000 Torr)MKS |
| Linear: 0 – 10 VDC (0–1 Torr)MKS | |
| Power Requirements | 11.5 – 26.5 VDC, 0.1 A at 11.5 VDC, 1.6 W maxMKS |
| Accuracy | Factory calibrated for Air/N₂ within specified instrument accuracyMKS |
| Resolution | Least significant digit on each rangeMKS |
| Filament Type | Gold-plated TungstenMKS |
| Set Point Configuration | Single-pole, double-throw (SPDT)MKS |
| Set Point Contact Rating | 1 Amps at 30 VDC resistive, AC non-inductiveMKS |
| Connector | 9-pin subminiature-D maleMKS |
| Fitting Type | 1/2 inch VCR-type female fittingMKS |
| Internal Volume | 40 cm³ (2.5 in³)MKS |
| Exposed Materials | 304 stainless steel, borosilicate glass, Kovar, alumina, NiFe alloy, polyimideMKS |
| Electronic Casing | Aluminum extrusionMKS |
| Operating Temperature | 0 – 40 °C ambient, non-condensingMKS |
| Storage Temperature | -40 – 70 °CMKS |
| Maximum Bakeout Temperature | 150 °C (electronics removed)MKS |
| Weight | 340 g (12 oz)MKS |
| Compliance | CE, RoHSMKS |
| Protection Rating | IP20MKS |
