1 PCS new Siemens LFE50 Flame Relay #LYQ007
1 PCS new Siemens LFE50 Flame Relay #LYQ007
1 PCS new Siemens LFE50 Flame Relay #LYQ007
General Information (Siemens Original Factory Standard)
|
Parameter
|
Specification (LFE50)
|
Unit
|
Factory Notes (Original Description)
|
|
Brand
|
Siemens, Original Factory, Brand New Genuine Product
|
-
|
100% brand new Siemens original product (formerly Landis & GYR), manufactured in strict accordance with original factory quality control standards, factory tested before delivery to ensure consistent performance[4].
|
|
Product Model
|
LFE50 (Flame Relay; Optional Model: LFE50-110V)
|
-
|
Original factory model, unchanged, belonging to Siemens UV flame safeguard series, with fixed power supply and detection configuration; LFE50-110V is the 100-110V AC voltage version[2].
|
|
Product Type
|
UV Flame Safeguard, Flame Relay, Burner Flame Supervision Relay
|
-
|
Plug-in design, integrated with power section, self-checking electronic flame signal amplifier and flame indicator lamp, specialized for industrial burner flame supervision[2].
|
|
Application
|
Continuous Oil/Gas Burners, Industrial Combustion Systems, Burner Flame Supervision
|
-
|
Used with QRA50M/QRA51M UV flame detectors for flame supervision of continuously operating oil or gas burners; requires LEC1 series control unit for automatic burner startup and control[2][4].
|
|
Supply Voltage
|
AC 220-240V (-15% ~ +10%); LFE50-110V: AC 100-110V (-15% ~ +10%)
|
V AC
|
Dual voltage version available to adapt to different regional industrial power supply requirements, strong voltage fluctuation adaptability[1][2][4].
|
|
Mains Frequency
|
50-60 Hz ±6%
|
Hz
|
Adaptable to global common power frequency ranges, stable operation under frequency fluctuation within ±6%[1][2][4].
|
|
Power Consumption
|
Approx. 13 VA
|
VA
|
Low power consumption design, energy-saving and environment-friendly, suitable for long-term continuous operation in industrial scenarios[1][3].
|
|
Fuse Configuration
|
Built-in: 250 mA (Slow, 5×20 mm); External: Max 10 A (Slow)
|
-
|
Built-in slow-blow fuse protects internal components; external slow-blow fuse (max 10 A) ensures safe power supply connection[1].
|
|
Permissible Contact Loading
|
Max 2 A
|
A
|
Stable contact load capacity, matching the load requirements of industrial burner control circuits, ensuring reliable signal transmission[1][4].
|
|
Matching Flame Detectors
|
QRA50M, QRA51M (UV Flame Detectors)
|
-
|
Forms self-checking UV flame supervision system with QRA50M/QRA51M detectors, suitable for UV radiation detection of oil and gas burner flames[2][4].
|
|
Protection Class
|
IP40
|
-
|
IP40 protection grade effectively prevents dust and foreign objects from entering, protecting internal electronic components and ensuring stable operation in industrial environments[2][4].
|
|
Operating Temperature Range
|
-20 ~ +60 ℃ (Ambient); No Condensation Allowed
|
℃
|
Adaptable to harsh industrial on-site temperature fluctuations, stable performance in low-temperature and high-temperature environments without malfunction[2][4].
|
|
Relative Humidity
|
≤ 95% RH (Non-Condensing)
|
% RH
|
Strong humidity adaptability, suitable for humid industrial environments, effectively preventing moisture damage to internal components[4].
|
|
Mounting Position
|
Any Position (Control Cabinet/Panel Mounting; Direct Burner Mounting Optional)
|
-
|
Flexible mounting, applicable to various installation spaces; can be mounted in any position in control cabinets/panels or directly on burners[2].
|
|
Weight
|
1.5 kg (Net); 3 kg (Shipping)
|
kg
|
Net weight 1.5 kg, compact and lightweight design, convenient for installation and transportation; shipping weight includes packaging protection[1].
|
|
Housing Material
|
Impact-Proof, Heat-Resistant Plastic
|
-
|
Housing is made of impact-proof and heat-resistant plastic, effectively protecting internal components from mechanical damage and high-temperature influence[2].
|
