1 PCS NEW GESTRA NRG16-11 Level Electrode#LYQ007
1 PCS NEW GESTRA NRG16-11 Level Electrode#LYQ007
| Parameter | Specification |
|---|---|
| Type | NRG16-11 Conductivity Level Electrode |
| Application | Low-level limiting (alarm) for steam boilers & pressurized hot-water plants |
| Measuring Principle | Electrical conductivity of water |
| Compliance Standards | TRD 604, DIN EN 12952, DIN EN 12953 |
| Service Pressure | 32 bar at 238 °C |
| Connection | Thread G 3/4", DIN 228, PN 40 |
| Available Lengths | 500 mm, 1000 mm, 1500 mm, 2000 mm, 2500 mm, 3000 mm |
| Response Sensitivity | Standard: 10 µS/cm at 25 °C (cell constant 0.3 cm⁻¹)
|
| Electrical Connection | Four-pole connector, cable gland M16 |
| Protection Class | IP65 to EN 60529 |
| Max. Ambient Temperature | 70 °C |
| Materials | - Flange: 1.0460 (C22.8)
|
| Weight | Approx. 6.0 kg |
| Type Approvals | SEE-BG GL-WB-93-349001, GL 88091 HH, RINA ELE/96695/1, LR 98/20076, BV 10618/Bo, KR HMB06190-MS001, NKK 02A 012 |
| Compatible Controller | Level switch NRS 1-7 |
