1 PCS NEW RITTAL SK 3374100 Air-Water Heat Exchanger #LYQ007
1 PCS NEW RITTAL SK 3374100 Air-Water Heat Exchanger #LYQ007
| Parameter | Value |
|---|---|
| Model | SK 3374100 |
| Product Type | Air-Water Heat Exchanger |
| Mounting | Wall-mounted |
| Cooling Capacity (L35W10, 400 l/h) | 3000 W (10236 BTU) |
| Supply Voltage | 230 VAC, 1-phase, 50/60 HzRittal |
| Rated Current (50 Hz) | 0.76 ARittal |
| Rated Current (60 Hz) | 1.01 ARittal |
| Power Consumption (50 Hz) | 169 WRittal |
| Power Consumption (60 Hz) | 232 WRittal |
| Air Flow Rate (50 Hz) | 1150 m³/h |
| Air Flow Rate (60 Hz) | 1300 m³/h |
| Permissible Operating Pressure | 1–10 bar (14.5–145 psi) |
| Water Inlet Temperature | 1–30 °C |
| Ambient Operating Temperature | 1–70 °CRittal |
| Protection Class | IP55 (EN 60529)Rittal |
| UL Type | 1, 3R, 12Rittal |
| Dimensions (W×H×D) | 400 × 950 × 145 mmRittal |
| Weight | 23.043 kg (50.7 lbs)Rittal |
| Water-Carrying Parts | Copper/Brass (Cu/CuZn) |
| Fuse Rating | 4 ARittal |
| Color | RAL 7035Rittal |
