1 PCS used NIKKI DENSO NCR-CDA1A2A-752 servo drive #LYQ007
1 PCS used NIKKI DENSO NCR-CDA1A2A-752 servo drive #LYQ007
1 PCS used NIKKI DENSO NCR-CDA1A2A-752 servo drive #LYQ007
| Parameter No. | Parameter Name | Unit | Factory Default | Min | Max | Access | Description |
|---|---|---|---|---|---|---|---|
| P000 | System Initialization | - | 0 | 0 | 1 | R/W | 0: No action; 1: Reset all parameters to factory defaults |
| P001 | Motor Pole Pair Number | - | 16 | 1 | 256 | R/W | Number of motor pole pairs for speed/position calculation |
| P002 | Encoder Resolution Selection | - | 0 | 0 | 2 | R/W | 0: 2000ppr; 1: 17bit (131072); 2: User-defined |
| P003 | Position Loop Gain | 1/s | 200 | 50 | 1000 | R/W | Main position loop proportional gain |
| P004 | Position Loop Integral Time | ms | 50 | 10 | 500 | R/W | Position loop integral time constant |
| P005 | Speed Loop Gain | 1/s | 1500 | 300 | 5000 | R/W | Speed loop proportional gain |
| P006 | Speed Loop Integral Time | ms | 20 | 5 | 200 | R/W | Speed loop integral time constant |
| P007 | Speed Filter Time Constant | ms | 5 | 1 | 50 | R/W | Speed feedback low-pass filter |
| P008 | Torque Limit | % | 100 | 10 | 200 | R/W | Rated torque percentage limit |
| P009 | Overload Factor | - | 150 | 100 | 300 | R/W | Overload current factor (1% = 1%) |
| P010 | Magnetic Pole Sensor Selection | - | 0 | 0 | 1 | R/W | 0: No sensor; 1: Use magnetic pole sensor |
| P011 | Position Feedback Pulse Number | ppr | 131072 | 1024 | 1048576 | R/W | Full-closed feedback pulses per motor rotation |
| P012 | Position Deviation Limit | pulse | 1000 | 100 | 10000 | R/W | Position deviation alarm threshold |
| P013 | Speed Command Filter | ms | 2 | 0 | 50 | R/W | Speed command low-pass filter |
| P014 | Torque Command Filter | ms | 2 | 0 | 50 | R/W | Torque command low-pass filter |
| P015 | Home Position Offset | pulse | 0 | -999999 | 999999 | R/W | Home position offset value |
| P016 | Alarm Clear | - | 0 | 0 | 1 | R/W | 0: No action; 1: Clear latched alarms |
| P017 | Servo On Delay | ms | 0 | 0 | 5000 | R/W | Delay from SON to servo enable |
| P018 | Servo Off Deceleration | ms | 500 | 100 | 10000 | R/W | Deceleration time when servo turns off |
| P019 | Override Speed | % | 100 | 10 | 200 | R/W | Speed override percentage |
| P020 | Position Loop Feedforward | - | 0 | 0 | 100 | R/W | Position feedforward gain (%) |
| P100 | Acceleration Time 1 | ms | 1000 | 100 | 60000 | R/W | First acceleration/deceleration time |
| P101 | Speed 1 | r/min | 3000 | 10 | 6000 | R/W | First operating speed |
| P102 | Positioning Target 1 | pulse | 0 | -99999999 | 99999999 | R/W | First positioning target |
| P103 | Acceleration Time 2 | ms | 2000 | 100 | 60000 | R/W | Second acceleration/deceleration time |
| P104 | Speed 2 | r/min | 1500 | 10 | 6000 | R/W | Second operating speed |
| P105 | Positioning Target 2 | pulse | 10000 | -99999999 | 99999999 | R/W | Second positioning target |
| P200 | Closed Loop Control Mode | - | 0 | 0 | 2 | R/W | 0: Position; 1: Speed; 2: Torque |
| P201 | Position Feedback Selection | - | 0 | 0 | 1 | R/W | 0: Encoder; 1: Full-closed |
| P202 | Speed Feedback Selection | - | 0 | 0 | 1 | R/W | 0: Motor encoder; 1: Load encoder |
| P203 | Torque Feedback Selection | - | 0 | 0 | 1 | R/W | 0: Estimated torque; 1: Direct torque |
| P204 | Control Mode Switching | - | 0 | 0 | 1 | R/W | 0: Disabled; 1: Enabled via I/O |
| P205 | Position Command Source | - | 0 | 0 | 2 | R/W | 0: Pulse; 1: Analog; 2: Communication |
| P206 | Speed Command Source | - | 0 | 0 | 2 | R/W | 0: Internal; 1: Analog; 2: Communication |
| P207 | Torque Command Source | - | 0 | 0 | 2 | R/W | 0: Internal; 1: Analog; 2: Communication |
| P300 | Over Voltage Protection Level | V | 420 | 380 | 500 | R/W | Over voltage threshold (AC200V series) |
| P301 | Under Voltage Protection Level | V | 160 | 140 | 200 | R/W | Under voltage threshold (AC200V series) |
| P302 | Over Current Protection Level | A | 180 | 120 | 300 | R/W | Over current threshold |
| P303 | Over Temperature Protection Level | ℃ | 80 | 60 | 100 | R/W | Over temperature threshold |
| P304 | Overload Protection Time | s | 1 | 0.1 | 10 | R/W | Overload protection duration |
| P400 | Communication Baud Rate | - | 3 | 0 | 6 | R/W | 0:9.6k; 1:19.2k; 2:38.4k; 3:57.6k; 4:115.2k; 5:230.4k; 6:460.8k |
| P401 | Communication Address | - | 1 | 1 | 31 | R/W | Modbus RTU slave address |
| P402 | Communication Timeout | ms | 1000 | 100 | 10000 | R/W | Communication timeout |
| P403 | Notch Filter Center Frequency 1 | Hz | 0 | 0 | 4999 | R/W | First notch filter center frequency |
| P404 | Notch Filter Bandwidth 1 | Hz | 0 | 0 | 4999 | R/W | First notch filter bandwidth |
| P405 | Notch Filter Center Frequency 2 | Hz | 0 | 0 | 4999 | R/W | Second notch filter center frequency |
| P406 | Notch Filter Bandwidth 2 | Hz | 0 | 0 | 4999 | R/W | Second notch filter bandwidth |
| P500 | I/O Signal Assignment DI1 | - | 0 | 0 | 63 | R/W | DI1 signal assignment |
| P501 | I/O Signal Assignment DI2 | - | 1 | 0 | 63 | R/W | DI2 signal assignment |
| P502 | I/O Signal Assignment DI3 | - | 2 | 0 | 63 | R/W | DI3 signal assignment |
| P503 | I/O Signal Assignment DO1 | - | 0 | 0 | 63 | R/W | DO1 signal assignment |
| P504 | I/O Signal Assignment DO2 | - | 1 | 0 | 63 | R/W | DO2 signal assignment |
| P505 | I/O Signal Assignment DO3 | - | 2 | 0 | 63 | R/W | DO3 signal assignment |
| P600 | Pulse Input Polarity | - | 0 | 0 | 1 | R/W | 0: Normal; 1: Inverted |
| P601 | Pulse Input Filter | μs | 10 | 0 | 100 | R/W | Pulse input filter time |
| P602 | Analog Input Scale | % | 100 | 50 | 200 | R/W | Analog input gain scale |
| P603 | Analog Input Offset | % | 0 | -50 | 50 | R/W | Analog input offset |
| P700 | Auto-Tuning Execution | - | 0 | 0 | 1 | R/W | 0: No; 1: Execute auto-tuning |
| P701 | Auto-Tuning Gain Level | - | 2 | 1 | 5 | R/W | Auto-tuning gain level (1=low, 5=high) |
| P702 | Auto-Tuning Complete Flag | - | 0 | 0 | 1 | R | 0: Incomplete; 1: Complete |
| P703 | Magnetic Pole Detection | - | 0 | 0 | 1 | R/W | 0: No; 1: Execute detection |
| P704 | Magnetic Pole Detection Complete | - | 0 | 0 | 1 | R | 0: Incomplete; 1: Complete |
| P800 | Fault Recovery | - | 0 | 0 | 1 | R/W | 0: No; 1: Attempt recovery |
| P801 | Fault History Clear | - | 0 | 0 | 1 | R/W | 0: No; 1: Clear fault history |
| P802 | Fault Code | - | 0 | 0 | 255 | R | Current fault code |
| P803 | Run Status | - | 0 | 0 | 3 | R | 0: Stop; 1: Run; 2: Jog; 3: Home |
| P804 | Actual Speed | r/min | 0 | -6000 | 6000 | R | Current motor speed |
| P805 | Actual Position | pulse | 0 | -99999999 | 99999999 | R | Current motor position |
| P806 | Actual Torque | % | 0 | -200 | 200 | R | Current torque output (%) |
| P807 | DC Bus Voltage | V | 0 | 0 | 500 | R | Current DC bus voltage |
| P808 | Motor Temperature | ℃ | 25 | 0 | 150 | R | Motor temperature (if equipped) |
| P809 | Driver Temperature | ℃ | 25 | 0 | 150 | R | Driver internal temperature |
| P810 | Position Deviation | pulse | 0 | -999999 | 999999 | R | Current position deviation |
