Parameter Item    Specification
Model Number    O3PZ0114006
Sensor Type    Diffuse Photoelectric Sensor
Sensing Range    0...400 mm (white paper 90% reflection, 20×20mm)
Light Source    Red LED (660 nm)
Switching Output    PNP, NO (Normally Open)
Output Current    ≤ 200 mA (load)
Supply Voltage    10...30 V DC
Voltage Ripple    ≤ 10 % (p-p)
Power Consumption    ≤ 30 mA (no load)
Switching Frequency    ≤ 200 Hz
Response Time    ≤ 2.5 ms (on/off)
Light/Dark Switching    Light-operated (LIGHT-ON), factory-set
Adjustment    Potentiometer (sensitivity)
Protection Class    IP67
Enclosure Material    Housing: PA; Front: PMMA
Operating Temperature    -25...+55 °C
Storage Temperature    -40...+70 °C
Connection Type    4-pin M12 male connector, axial
Mechanical Design    Compact rectangular design
Certifications    CE, cULus, EAC, RoHS

1  .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
 Including : frequency converter, servo driver, servo motor,   data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial   computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
 3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please    contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
