1 PCS new Telco Photoelectric Sensor SMP6000SGT3 #LYQ007
1 PCS new Telco Photoelectric Sensor SMP6000SGT3 #LYQ007
| Parameter Category | Parameter Name | SMP6000SGT3 (SMT6000SG T3) Specification |
|---|---|---|
| Basic Information | Product Model | SMP6000SGT3 (SMT6000SG T3) |
| Manufacturer | Telco Sensors (Denmark) | |
| Product Type | Thru‑beam photoelectric sensor (Transmitter) | |
| Series | SM6000 (SpaceMaster) | |
| Connection | 3‑pin M8 connector | |
| Core Detection Parameters | Detection Principle | Infrared thru‑beam detection |
| Light Source | Infrared (880 nm) | |
| Max Sensing Range | 6 m (adjustable 1–6 m) | |
| Emission Angle | ±10° | |
| Response Time | 5 ms (typical) | |
| Operating Frequency | Max 100 Hz | |
| Sensitivity Adjustment | Via control input (COM‑input) | |
| Electrical Parameters | Supply Voltage | 10–32 VDC |
| Voltage Ripple | ±15% | |
| Current Consumption | Max 30 mA @ 32 VDC | |
| Protection | Reverse polarity protected; short‑circuit protected | |
| Indicator | Green LED (Power ON) | |
| Mechanical Parameters | Dimensions | 9.5 × 11.5 × 60 mm |
| Housing Material | Polyester (body); Polycarbonate (front lens) | |
| Cable | 3 × 0.14 mm²; PVC sleeve Ø4.0 mm | |
| Weight | Approx. 30 g | |
| Environmental Parameters | Operating Temperature | −20 °C to +60 °C |
| Storage Temperature | −40 °C to +80 °C | |
| Humidity | 0–95% RH (non‑condensing) | |
| Vibration Resistance | 10–55 Hz, 0.5 mm amplitude | |
| Shock Resistance | 30 g | |
| Protection Class | IP67 | |
| Light Immunity | >50,000 lux | |
| Approvals | Certifications | CE compliant |
| Warranty | 3‑year worldwide warranty |
