Part Number: A6500-UM; Product Name: Emerson Industrial Control Module
Brand: Emerson (A global leader in automation, process control, and power management solutions, delivering reliable products for industrial and commercial applications);
Product Status: Original New Unit; Product Category: Industrial Grade Control Card, designed for data acquisition, logic control, and system integration in Emerson automation systems.
Core Application: Specifically compatible with Emerson DeltaV / Ovation DCS systems, widely used in oil & gas, chemical processing, power generation, water treatment, and pharmaceutical industries. It enables real-time data transmission, precise process control, and system status monitoring, ensuring stable and efficient operation of the entire automation system.
Core Features: High-precision data acquisition capability; Seamless integration with Emerson DCS main units; Multiple communication protocols support for flexible system expansion; Excellent anti-interference performance in harsh industrial environments; Compliance with international industrial safety and quality standards.
2. Electrical Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Power Supply Parameters
Supply Voltage: +24 VDC (Main Power Supply); Voltage Tolerance: ±15% (20.4 VDC ~ 27.6 VDC);
Power Consumption: ≤ 6 W (Normal Operation); Standby Power Consumption: ≤ 1.2 W;
Isolation Voltage: 2500 VAC (Between Control Circuit and Power Circuit, Duration 1 min, per IEC 61140 Standard).
2.2 Signal Processing Parameters
Analog Input Channels: 8 Channels (Differential Input, 0~10 VDC / 4~20 mA Selectable);
Analog Input Resolution: 16 Bits; Input Accuracy: ±0.05% FSR (Full Scale Range);
Analog Output Channels: 4 Channels (0~10 VDC / 4~20 mA Selectable, Load Capacity: ≤ 600 Ω);
Digital Input Channels: 16 Channels (Dry Contact / PNP/NPN Open Collector, 24 VDC Rated);
Digital Output Channels: 8 Channels (Relay Output, Contact Rating: 250 VAC / 30 VDC, 8 A Max).
2.3 Communication Parameters
Communication Protocol: HART (Standard), Modbus RTU, Optional Foundation Fieldbus;
Communication Interface: RS485 (Half-Duplex) / Ethernet (RJ45), Opto-Isolated Protection;
Baud Rate: 9600 ~ 38400 bps (Selectable); Data Bits: 8; Stop Bits: 1 / 2 (Selectable); Parity: None / Odd / Even (Selectable); Ethernet Speed: 10/100 Mbps (Auto-Negotiation).
2.4 Response Performance
Signal Response Time: ≤ 0.8 ms (Analog Signal); Logic Processing Delay: ≤ 1.5 ms;
Sampling Frequency: Up to 20 kHz (Analog Input Channels).
