1 pc for used Rexroth Servo Motor MSK040B-0300-NN-M1-UG0-NNNN (R911308506)#LYQ007
1 pc for used Rexroth Servo Motor MSK040B-0300-NN-M1-UG0-NNNN (R911308506)#LYQ007
| Parameter | Symbol | Unit | Value |
|---|---|---|---|
| General | |||
| Motor Type | Synchronous Servo Motor (IndraDyn S MSK) | ||
| Part Number | MSK040B-0300-NN-M1-UG0-NNNN | ||
| Order Code | R911308506 | ||
| Electrical Data | |||
| Continuous Torque (Standstill, 60 K) | M₀_60 | Nm | 1.7 |
| Continuous Current (Standstill, 60 K) | I₀_60(rms) | A | 6.0 |
| Maximum Torque | M_max | Nm | 5.1 |
| Maximum Current | I_max(rms) | A | 18.0 |
| Torque Constant (20 °C) | K_M | Nm/A | 0.28 |
| Voltage Constant (20 °C) | K_EMK_1000 | V/min⁻¹ | 17.5 |
| Winding Resistance (20 °C) | R₁₂ | Ω | 1.80 |
| Winding Inductance | L₁₂ | mH | 3.8 |
| Discharge Capacity | C_dis | nF | 1.8 |
| Number of Pole Pairs | p | – | 4 |
| Mechanical Data | |||
| Maximum Speed | n_max | min⁻¹ | 6000 |
| Rotor Moment of Inertia | J_rot | kg·m² | 0.00014 |
| Thermal Time Constant | T_th | min | 14.0 |
| Weight | m | kg | 4.4 |
| Environmental & Protection | |||
| Operating Ambient Temp | T_amb | °C | 0 … 40 |
| Storage Temp | °C | -20 … +60 | |
| Protection Class (IP) | IP65 | ||
| Insulation Class | Class 155 (EN 60034‑1) | ||
| Sound Pressure Level | L_P | dB(A) | <75 |
| Encoder & Options | |||
| Encoder Type | Multi‑turn Absolute (M1) | ||
| Encoder Interface | Hiperface | ||
| Encoder Resolution | 2048 increments | ||
| Holding Brake | None (NN) | ||
| Cooling | Natural Convection (NN) | ||
| Shaft | Smooth (G) | ||
| Mechanical Mounting | |||
| Mounting Type | Flange (IM B5) | ||
| Flange Diameter | mm | 109 | |
| Shaft Diameter | mm | 14 | |
| Mounting Hole | M6×20 | 4× | |
| Tightening Torque | Nm | 10.4 |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
