1PCS used SKM36-HFA0-S01 SICK multiturn absolute motor

Sale price $188.00
40 People are viewing this right now
Add to Wishlist
Add to Compare

1PCS used SKM36-HFA0-S01 SICK multiturn absolute motor
1PCS used SKM36-HFA0-S01 SICK multiturn absolute motor
Sale price$188.00
1PCS used SKM36-HFA0-S01 SICK multiturn absolute motor

1PCS used SKM36-HFA0-S01 SICK multiturn absolute motor

$188.00
The SKM36-HFA0-S01 is a SICK multiturn absolute motor feedback encoder with HIPERFACE® interface, tailored for servo motor closed-loop control in industrial automation. Below are its full English technical specificationsSICK.

Category Specifications
Basic Information Model: SKM36-HFA0-S01

Brand: SICK

Type: Multiturn absolute motor feedback encoder

Interface: HIPERFACE®

Code Principle: SinCos photoelectric detection (128 periods/rev)

Resolution: Single-turn: 4096 increments; Multiturn: 4096 revolutions (Total 16,777,216 steps)

Safety Certification: SIL2/PLd, RoHS-compliant
Electrical Data Supply Voltage: 7 V DC - 12 V DC (recommended 8 V DC)

Current Consumption: ≤ 60 mA (no load)

Output Frequency: Sin/Cos ≤ 65 kHz

Connection: 8-pin radial male connector

Insulation Resistance: ≥ 100 MΩ (500 V DC)

Dielectric Strength: 500 V AC (50 Hz, 60 s)

EEPROM: 1792 bytes
Mechanical Data Shaft Type: Tapered shaft

Flange/Stator Coupling: Spring mounting plate

Weight: ≤ 0.07 kg

Rotor Moment of Inertia: 4.5 g·cm²

Operating Speed: 9,000 min⁻¹

Angular Acceleration: ≤ 500,000 rad/s²

Operating Torque: 0.2 N·cm

Start-up Torque: +0.3 N·cm

Permissible Movement (Static): Radial ±0.2 mm; Axial -1.4 mm to +0.6 mm

Permissible Movement (Dynamic): Radial ±0.05 mm

Ball Bearing Life: 3.6×10⁹ revolutions

Protection Class: IP50
Environmental Data Operating Temperature: -20 °C - +110 °C

Storage Temperature: -40 °C - +125 °C (unpackaged)

Relative Humidity: ≤ 90% (non-condensing)

Shock Resistance: 100 g, 6 ms (EN 60068-2-27)

Vibration Resistance: 50 g, 10 Hz - 2000 Hz (EN 60068-2-6)

EMC Compliance: EN 61000-6-2, EN 61000-6-3
