1 PCS used Yaskawa SGMGH-75A2A-YR14 Servo Motor Specs #LYQ007
1 PCS used Yaskawa SGMGH-75A2A-YR14 Servo Motor Specs #LYQ007
| Parameter Category | Parameter Name | Value | Unit |
|---|---|---|---|
| Electrical Ratings | Rated Voltage | 3-Phase AC200 | V |
| Rated Output Power | 7.5 (10) | kW (hp) | |
| Rated Torque | 48 | N·m | |
| Instantaneous Peak Torque | 119 | N·m | |
| Rated Current (RMS) | 54.7 | A | |
| Instantaneous Max Current (RMS) | 130 | A | |
| Mechanical Ratings | Rated Speed | 1500 | r/min |
| Maximum Speed | 3000 | r/min | |
| Rotor Inertia | 125 × 10⁻⁴ | kg·m² | |
| Rated Angular Acceleration | 3850 | rad/s² | |
| Electrical Characteristics | Torque Constant (20°C) | 8.2 (0.93) | N·m/A (lb·in/A) |
| Coil Resistance (20°C) | 111 | mΩ | |
| Inertia Time Constant | 1.1 | ms | |
| Inductive Time Constant | 18.4 | ms | |
| Encoder | Type | 17-bit Absolute (Serial) | - |
| Environmental | Protection Class | IP67 (Excl. Shaft Extension) | - |
| Ambient Temperature | 0 to +40 | °C | |
| Ambient Humidity | 20 to 80 (Non-Condensing) | %RH | |
| Insulation Class | F | - | |
| Vibration Resistance | V15 | - | |
| Mechanical | Mounting | Flange | - |
| Cooling | Self-Cooled | - | |
| Shaft Type | Taper 1/10 with Parallel Key (per SGMGH-75A2A config) | - | |
| Special | Option Code YR14 | Custom Spec (Consult Yaskawa for Exact Details) | - |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
