1 PCS USED Bosch Rexroth Servo Motor MKD041B-144-KG0-KN (R911260464) #LYQ007
1 PCS USED Bosch Rexroth Servo Motor MKD041B-144-KG0-KN (R911260464) #LYQ007
| Parameter | Value |
|---|---|
| Manufacturer | Bosch Rexroth (Indramat) |
| Model | MKD041B-144-KG0-KN |
| Order No. | R911260464 |
| Product Type | Synchronous Servo Motor |
| Motor Series | MKD |
| Motor Size | 041 |
| Motor Length | B |
| Winding Code | 144 |
| Feedback System | Resolver with integrated multi-turn absolute encoder (Absolute > 4096 revolutions) |
| Holding Brake | Without holding brake |
| Shaft Design | Plain shaft with shaft seal ring |
| Connection Direction | Side B |
| Flange Size | 82 mm |
| Centering Diameter | 50 mm |
| Protection Class | IP65 |
| Insulation Class | F |
| Cooling Method | Natural convection |
| Rated Torque (at 100K) | 1.5 Nm |
| Continuous Torque at Standstill | 2.7 Nm |
| Theoretical Maximum Torque | 11.3 Nm |
| Rated Speed (at 100K) | 4500 rpm |
| Max. Permissible Speed | 6000 rpm |
| Rated Power | 0.88 kW |
| Rated Voltage | 170 V |
| Rated Current | 3 A |
| Peak Current | 34 A |
| Winding Inductance | 5 mH |
| Number of Pole Pairs | 3 |
| Moment of Inertia | 0.72 kg·cm² (7.2 × 10⁻⁵ kg·m²) |
| Weight | 4.4 kg (19.44 lbs) |
| Operating Temperature | 0 °C to +40 °C |
| Storage Temperature | -20 °C to +80 °C |
| Max. Installation Altitude | 1000 m above sea level |
| Mounting Screws | 4 × M6, tightening torque 10.4 Nm, strength class 8.8 |
