1 PCS used Jenaer Servo Motor 23S31-0560-805J7-52(200) #LYQ007
1 PCS used Jenaer Servo Motor 23S31-0560-805J7-52(200) #LYQ007
1 PCS used Jenaer Servo Motor 23S31-0560-805J7-52(200) #LYQ007
Original Factory Precision Parameters (Model: Jenaer Servo Motor 23S31-0560-805J7-52(200))
|
Parameter Category
|
Parameter Name
|
Original Factory Precision Specification
|
|
Basic Information
|
Product Model
|
23S31-0560-805J7-52(200); Jenaer ECOSTEP 23S Series Genuine Original Servo Motor, 100% unused and unrefurbished genuine parts, consistent with Jenaer's official model coding standards. It belongs to high-precision two-phase synchronous servo motor, designed for dedicated matching with various industrial automation control systems, with fixed configuration and excellent environmental compatibility, focusing on high-precision positioning, high torque and high efficiency.
|
|
Manufacturer Standard
|
Manufactured by Jenaer (JAT Jenaer Antriebstechnik GmbH, Genuine Original Factory); Compliant with ISO 9001 Quality Certification, CE, RoHS, IEC 60034 (Rotating Electrical Machines), IEC 61800 (Adjustable Speed Electrical Power Drive Systems) Industrial Standards; Conforms to Jenaer Internal Technical Standard and ECOSTEP 23S Series Manufacturing Norms, as well as EMC Standards EN 55011 (Emission) and EN 55022 (Immunity), meeting the precision calibration requirements of international high-precision servo motor standards.
|
|
|
Product Series
|
Jenaer ECOSTEP 23S Series; Two-phase synchronous servo motor; Designed for dynamic and high-precision positioning with high torque relative to its size; Available with various optional configurations such as different encoder types, cable lengths, holding brakes and couplings to adapt to different application scenarios.
|
|
|
Core Electrical & Drive Parameters
|
Motor Type
|
High-Precision Two-Phase Synchronous Servo Motor; Brushless Design; N-Channel Drive Compatible; Integrated high-efficiency stator and rotor structure, supporting AC/DC hybrid drive mode; Built-in high-precision feedback module, realizing closed-loop control, suitable for high-precision motion control scenarios.
|
|
Rated Supply Voltage
|
Rated Value: 60V DC; Tolerance: ±10%; Compatible with 60V DC power supply system, consistent with ECOSTEP 23S series standard voltage configuration; Stable voltage adaptation, no abnormal operation under rated voltage fluctuation range; Test standard: IEC 60034-1.
|
|
|
Rated Output Power
|
Rated Value: 200W (Consistent with model suffix (200)); Tolerance: ±3%; Maximum Output Power: 400W (Short-Time, 10s); High power density, perfect balance between power output and volume, meeting high-efficiency drive requirements of small and medium-sized industrial equipment.
|
|
|
Rated Torque
|
Rated Value: 0.637N·m (0.47 ft·lb); Peak Torque: 1.8N·m (1.3276 ft·lb); Tolerance: ±5%; High torque output at low speed, stable torque performance during operation, no obvious torque fluctuation, ensuring stable load driving; Consistent with ECOSTEP 23S series torque configuration range.
|
|
|
Rated Speed
|
Rated Value: 3000rpm (18849.56 rad/min); Minimum Operating Speed: 750rpm (4712.39 rad/min); Tolerance: ±1%; High-speed stability, small speed fluctuation (≤±0.1%), suitable for high-speed and high-precision motion control scenarios; Adjustable speed range: 750rpm ~ 3000rpm.
|
|
|
Rated Current
|
Rated Value: 4.5A RMS; Peak Current: 13.5A RMS; Tolerance: ±5%; Low no-load current, high current utilization rate, reducing energy loss; Built-in current limiting protection, preventing overcurrent damage to the motor.
|
|
|
Back EMF Constant
|
Rated Value: 18mV/rpm; Tolerance: ±3%; Stable back EMF performance, ensuring smooth speed regulation and precise torque control; Effectively reducing motor heating during high-speed operation, improving operational efficiency and service life.
|
|
|
Winding Resistance & Inductance
|
Winding Resistance (Phase to Phase): 1.8Ω ±5% (25℃); Winding Inductance (Phase to Phase): 8.5mH ±10% (1kHz); Symmetrical winding parameters, ensuring stable motor operation and precise control performance; High insulation performance, preventing winding short circuit.
|
|
|
Positioning & Feedback Parameters
|
Feedback Device
|
High-Precision Incremental Encoder; Resolution: 2500 Lines (10000 Pulses/Rev); Output Signal: A, B, Z (Differential); Response Frequency: Up to 500kHz; High anti-interference performance, ensuring accurate position feedback and closed-loop control, matching Jenaer standard feedback module specifications.
|
|
Positioning Accuracy
|
Repeat Positioning Accuracy: ±0.01mm (at 1m travel); Absolute Positioning Accuracy: ±0.02mm (at 1m travel); High positioning precision, meeting the requirements of high-precision machining and positioning scenarios, consistent with ECOSTEP 23S series high-precision positioning performance.
|
|
|
Speed Fluctuation
|
Rated Speed Fluctuation: ≤±0.1%; No-Load Speed Fluctuation: ≤±0.05%; Stable speed performance, no obvious speed drift during long-term operation, ensuring uniform motion of the equipment and improving processing quality.
|
|
|
Encoder Protection Level
|
Protection Level: IP65; Sealed design, effectively preventing dust, water splashing and oil pollution from entering the encoder, ensuring stable feedback performance in harsh industrial environments; Compatible with motor overall protection level.
|
|
|
Protection & Anti-Interference Parameters
|
Comprehensive Protection Functions
|
Electrical Protection: Overcurrent Protection, Overvoltage Protection, Undervoltage Protection, Winding Overheating Protection (Trigger Temperature: ≥155℃); Mechanical Protection: Overload Protection (150% Rated Load, 1min); Operational Protection: Encoder Fault Protection, Rotor Lock Protection; Automatic power-off protection when fault occurs, effectively protecting the motor and connected equipment.
|
|
Anti-ESD Performance
|
Anti-Electrostatic Discharge (ESD): ±25kV (Air), ±15kV (Contact); Complying with IEC 61000-4-2 standard; Effectively resisting static interference in industrial installation and operation processes; Preventing static damage to the motor's internal circuit and encoder.
|
|
|
EMC Compliance
|
Emission: EN 55011 Class B; Immunity: EN 55022 Class B; Anti-Electromagnetic Interference (EMI): ≥2500V AC (Isolation); Effectively resisting industrial electromagnetic interference, ensuring stable operation in complex electromagnetic environments such as industrial production lines.
|
|
|
Insulation Performance
|
Insulation Resistance (Phase to Ground): ≥1000MΩ (500V DC); Insulation Strength: 2.5kVrms (1 Minute), No Breakdown or Flashover; High insulation performance, effectively preventing short circuit between windings and motor shell, ensuring safe operation.
|
|
|
Environmental & Physical Parameters
|
Operating Environment
|
Operating Temperature: -20℃ ~ 80℃; Storage Temperature: -40℃ ~ 100℃; Operating Humidity: 10% ~ 90% RH (Non-Condensing); Storage Humidity: < 80% RH (Non-Condensing); Cooling Method: Natural Cooling + Forced Air Cooling (Optional); Protection Grade: IP65 (Overall), effectively preventing dust, water splashing and oil pollution from entering the motor.
|
|
Physical Dimensions
|
Overall Dimensions: 110mm (Length) × 60mm (Diameter) (±0.5mm); Shaft Diameter: 14mm (±0.01mm); Shaft Length: 25mm; Weight: ≤1.8kg (Without Accessories); Housing Material: High-temperature Resistant Aluminum Alloy (Anti-Corrosion, Anti-Oxidation); Installation Method: Flange Mounting (Jenaer Standard Flange Size), compact structure, easy to install and maintain.
|
|
|
Durability & Service Life
|
Vibration Resistance: 3g (10Hz ~ 500Hz); Shock Resistance: 15g (11ms); Service Life: ≥20000 Operating Hours (Under Rated Working Conditions); Bearing Service Life: ≥50000 Hours; Low noise operation (≤55dB at 1m), long-term stable operation under harsh industrial environments, low failure rate; Consistent with Jenaer's high-durability product standards.
|
