1 PCS Nidec EV2100-4T0900A Inverter #LYQ007
1 PCS Nidec EV2100-4T0900A Inverter #LYQ007
| Item | Specification |
|---|---|
| Model | EV2100-4T0900A |
| Applicable Motor Power | 90 kW |
| Rated Capacity | 116 kVA |
| Input | |
| Phase / Voltage | 3-phase, 380–440 V |
| Frequency | 50/60 Hz ±5% |
| Voltage Range | 320–460 V, voltage unbalance ≤3% |
| Rated Input Current | 180 A |
| Output | |
| Rated Output Current | 176 A |
| Output Frequency | 0–550 Hz |
| Overload Capacity | 110% rated current for 1 min; 150% for 2 s |
| Modulation | Flux vector PWM |
| Control Performance | |
| Starting Torque | 150% rated torque at 0.5 Hz |
| Speed Regulation Accuracy | ≤±0.5% of rated synchronous speed |
| Frequency Accuracy | Digital: ±0.01% of max frequency; Analog: ±0.2% of max frequency |
| Frequency Resolution | Digital: 0.01 Hz; Analog: 0.1% of max frequency |
| Torque Boost | Auto/manual (0.1–30.0%) |
| Environmental & Mechanical | |
| Cooling | Forced air cooling |
| Ambient Temp | -10 to +40 °C (derate above 40 °C) |
| Humidity | ≤95% RH (non-condensing) |
| Altitude | ≤1000 m (derate above 1000 m) |
| Vibration | ≤5.9 m/s² (0.6 g) |
| Dimensions (W×H×D) | 468 × 770 × 301 mm |
| Mounting Hole | φ10 mm |
| Net Weight | 90 kg (excl. DC reactor) |
| Protection & Features | |
| Protection | Overvoltage, undervoltage, overcurrent, overheat, phase loss, etc. |
| Main Functions | Motor auto-tuning, AVR, auto carrier adjustment, S-curve acceleration/deceleration, PI control, sleep mode, multi-speed operation |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
