1 PCS used MORIKAWA Inverter H500B-4T-15-P#LYQ007
1 PCS used MORIKAWA Inverter H500B-4T-15-P#LYQ007
1 PCS used MORIKAWA Inverter H500B-4T-15-P#LYQ007
Original Factory Precision Parameters (Model: MORIKAWA Inverter H500B-4T-15-P)
|
Parameter Category
|
Parameter Name
|
H500B-4T-15-P Specification
|
|
Basic Information
|
Product Model
|
H500B-4T-15-P; MORIKAWA Genuine Original Inverter, 100% unused and unrefurbished genuine parts; 3-phase 380V class, 15kW rated power
|
|
Manufacturer Standard
|
Manufactured by MORIKAWA; Compliant with CE, UL, CUL, EN 61010-1, IEC 61800-5-1 Standards; Conforms to MORIKAWA Internal Technical and Quality Norms
|
|
|
Product Application
|
Plastic Molding Equipment, Die Casting Machinery, Fans & Pumps, Conveyor Systems, Packaging Machinery, Medium-sized Processing Equipment, Industrial AC Motor Speed Control, Medium-sized Industrial Automation Production Lines, Compressors, Water Pumps, Ventilators, etc.
|
|
|
Core Frequency Conversion & Speed Regulation Parameters
|
Control Type
|
V/F Control, SVC (Sensorless Vector Control), VC (Vector Control); Multi-control mode switchable to adapt to different medium-sized load application scenarios
|
|
Rated Power
|
15 kW (20 HP); Consistent with MORIKAWA original factory calibration, ±1% precision
|
|
|
Input Voltage
|
3-phase AC 380~480 V; Voltage Tolerance: ±10%; Frequency: 47~63 Hz (Automatic Adaptation)
|
|
|
Output Voltage
|
3-phase AC 0~480 V; Proportional to input voltage and frequency, stepless adjustable; Output voltage precision: ±1%
|
|
|
Output Frequency Range
|
General Load: 0.01~600.00 Hz; Heavy Load: 0.00~300.00 Hz; Stepless frequency regulation, suitable for medium-sized load speed control; Frequency accuracy: ±0.01%
|
|
|
Frequency Precision
|
Digital Command: ±0.01% (-10℃~+40℃); Analog Command: ±0.1% (25±10℃); High precision frequency control, stable operation under long-term load
|
|
|
Frequency Resolution
|
Digital Command: 0.01 Hz; Analog Command: 0.03% of maximum output frequency (±11 bit); High resolution ensures precise speed regulation
|
|
|
Starting Torque
|
0.5 Hz: ≥150% rated torque; SVC/VC mode: 0 Hz: ≥180% rated torque, strong starting performance for heavy medium-sized loads
|
|
|
Core Electrical Parameters
|
Rated Input Current
|
30 A; Rated working current, ±1% precision, ensure stable power input, adapt to grid voltage fluctuations
|
|
Rated Output Current
|
32 A; Continuous output current, compatible with 15 kW AC motor, support long-term continuous operation
|
|
|
Overload Tolerance
|
General Load: 120% rated output current for 60 seconds; Heavy Load: 150% rated output current for 60 seconds; 200% rated output current for 0.5 seconds; Automatic protection after overload
|
|
|
Carrier Frequency
|
Heavy Load: 2~6 kHz; General Load: 2~15 kHz; Adjustable, reduce motor noise, suitable for quiet operation scenarios, carrier frequency precision: ±5%
|
|
|
Frequency Setting Signal
|
Analog Input: +10V~-10V, 0~+10V, 4~20mA, 0~20mA; Digital Input: Multi-channel optional, flexible setting for medium-sized equipment, support external potentiometer adjustment
|
|
|
Acceleration/Deceleration Time
|
Acceleration Time: 0.00~600.00 seconds; Deceleration Time: 0.0~6000.0 seconds; Stepless adjustable, S-curve acceleration/deceleration optional, adapt to different load start/stop requirements
|
|
|
Insulation Resistance
|
≥100 MΩ (500 V DC); Good insulation performance, safe and reliable for medium-sized industrial scenarios, effectively prevent electric leakage
|
|
|
Dielectric Strength
|
AC 1500 V, 50 Hz, 1 minute; No breakdown, no arcing; Ensure electrical safety, meet industrial grade safety standards
|
|
|
Protection & Safety Parameters
|
Over-temperature Protection
|
Inverter internal temperature ≥85℃: Alarm; ≥90℃: Cut off output and power supply; Built-in temperature sensor, real-time monitoring, prevent inverter damage caused by overheating
|
|
Over-voltage Protection
|
Input/Output Voltage ≥528 V: Alarm and cut off power supply; Avoid component damage caused by voltage surge, adapt to grid voltage fluctuations
|
|
|
Under-voltage Protection
|
Input Voltage ≤342 V: Alarm and cut off power supply; Avoid abnormal operation caused by low voltage, protect motor and inverter
|
|
|
Over-current Protection
|
Output Current ≥48 A: Alarm and cut off output; Protect inverter circuit and motor from over-current damage, respond quickly within 10ms
|
|
|
Short-circuit Protection
|
Output short-circuit: Instantaneous cut off power supply and alarm; Prevent fire and inverter burnout caused by short-circuit, high sensitivity protection
|
|
|
ESD Protection
|
±8 kV (Contact), ±15 kV (Air); Effectively protect the inverter from static damage, ensure stable operation in electronic manufacturing and other environments
|
|
|
Over-torque Protection
|
Maximum torque current: 200% rated torque current; Over-torque detection and alarm, protect medium-sized motor and equipment, avoid mechanical damage
|
|
|
Other Protections
|
Motor over-temperature protection, ground fault protection, input/output phase loss protection, memory loss protection, over-power protection; Comprehensive protection, safe and reliable, reduce equipment failure rate
|
|
|
Environmental & Structural Parameters
|
Operating Temperature
|
-10℃ ~ 55℃; Derating 1% per °C when exceeding 45℃; Adapt to various medium-sized industrial working environments, 50℃ high temperature resistant operation, low temperature resistance
|
|
Storage Temperature
|
-20℃ ~ 65℃; Stable storage performance, no performance degradation after long-term storage in warehouse or transportation, adapt to different regional climate conditions
|
|
|
Relative Humidity
|
5% ~ 95% (Non-Condensing); Resisting humid industrial environments, no short circuit or malfunction risk, suitable for high humidity workshops
|
|
|
Structure Material
|
Industrial-Grade FR-4 Circuit Board + Metal Shell; Anti-corrosion, anti-oxidation, high mechanical strength; Protective coating treatment, dust-proof design (IP20), suitable for cabinet installation in medium-sized equipment
|
|
|
Cooling Mode
|
Forced air cooling (detachable fan); Efficient heat dissipation, ensure long-term stable operation; Fan fault alarm function, suitable for continuous operation scenarios, easy to maintain and replace
|
|
|
Interface & Compatibility Parameters
|
Communication Interface
|
Standard RS485 (RJ45) Interface; Support Modbus RTU Communication Protocol; Baud Rate: Up to 115.2 kbps; Realize remote monitoring and control for medium-sized automation systems, easy for system integration
|
|
Control Interface
|
Digital Input/Output Interface; Programmable, convenient for external control and expansion; Support 3-wire control, 16-speed control (including main speed), suitable for medium-sized equipment control, flexible configuration
|
|
|
Configuration Interface
|
Digital Operator Interface (hot-swappable); Convenient for parameter setting, status monitoring and fault query; Parameter copy function supported, easy for batch configuration of multiple inverters
|
|
|
Equipment Compatibility
|
Suitable for 3-phase AC asynchronous motors and synchronous motors; Compatible with various MORIKAWA control systems; Matching 15 kW motors with 3-phase 380~480 V input, strong compatibility for medium-sized equipment, wide application range
|
|
|
Functional Parameters
|
V/F Curve
|
4-point arbitrary V/F curve & 2nd power curve; Adjustable, adapt to different medium-sized load characteristics (such as fan, pump, processing equipment), optimize energy consumption
|
|
Speed Response Ability
|
General mode: 5 Hz; Vector control mode: Up to 40 Hz; Fast speed response, ensure stable operation of medium-sized motors, reduce speed fluctuation
|
|
|
Torque Precision
|
±5% rated torque; High torque control precision, suitable for medium-sized torque control scenarios (such as medium-sized processing equipment), ensure processing accuracy
|
|
|
Special Functions
|
Zero servo control, instantaneous power failure restart, speed search, PID control (with sleep function), energy-saving control, abnormal restart, automatic tuning (rotational, stationary), dwell, slip compensation, torque compensation, JOG frequency setting, suitable for medium-sized industrial application scenarios, improve production efficiency
|
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
