1 PCS used KEB COMBIVERT F5 16.F5.M1E-34HA Inverter #LYQ007
1 PCS used KEB COMBIVERT F5 16.F5.M1E-34HA Inverter #LYQ007
| Parameter | Value |
|---|---|
| Model | 16.F5.M1E-34HA |
| Series | COMBIVERT F5-Multi (Synchronous Motor Control)KEB |
| Rated Power | 15 kWKEB |
| Supply Voltage | 3×380–480 VAC, 50/60 HzKEB |
| Output Current (Rated) | 33 AKEB |
| Output Current (Max/Peak) | 49.5 AKEB |
| Input Current (Rated) | 33 A |
| Switching Frequency | 2–16 kHz (default 4 kHz)KEB |
| Output Frequency Range | 0–800 Hz (option up to 1600 Hz)KEB |
| Control Modes | V/F, Sensorless Vector (SMM), Closed‑loop Vector (F5‑M), Torque ControlKEB |
| Housing | Size EKEB |
| Protection Class | IP20 (chassis)KEB |
| Ambient Temperature | −10 °C to +45 °C (derate above 40 °C)KEB |
| Storage Temperature | −25 °C to +70 °CKEB |
| Humidity | ≤95% RH, non‑condensingKEB |
| Dimensions (W×H×D) | 130 × 290 × 208 mmKEB |
| Weight | Approx. 8.5 kg |
| Control Terminals | 29 plug‑in terminals (PNP/NPN selectable)KEB |
| Analog Inputs | 2×: 0–10 V, ±10 V, 0/4–20 mA; 12‑bit resolutionKEB |
| Analog Outputs | 2×: 0–10 V, ±10 V; 11‑bit resolutionKEB |
| Digital Inputs | 8× programmable (13–30 VDC)KEB |
| Digital Outputs | 2× relay (30 VDC/1 A), 2× open‑collector (50 mA total)KEB |
| Encoder Interfaces | TTL, HTL, Resolver, Sin/Cos, EnDat, Hiperface, BiSS, SSIKEB |
| Communication | RS‑485, optional: Profibus, CANopen, DeviceNet, EtherNet/IP, EtherCAT, PROFINETKEB |
| Braking Chopper | Internal (GTR7)KEB |
| Motor Protection | PTC/KTY monitoring, overload, overcurrent, short‑circuitKEB |
| Certifications | CE, cULus (UL508)KEB |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
