1 PCS Allen‑Bradley 1336F‑B020‑AN‑EN inverter #LYQ007
1 PCS Allen‑Bradley 1336F‑B020‑AN‑EN inverter #LYQ007
| Parameter | Value |
|---|---|
| Manufacturer | Allen‑Bradley (Rockwell Automation) |
| Product Series | 1336 PLUS II Adjustable Frequency AC Drive |
| Catalog Number | 1336F‑B020‑AN‑EN |
| Product Type | Open Chassis AC Drive (No Enclosure) |
| Frame Size | B (B1/B2) |
| Enclosure / IP Rating | Open, IP00 |
| Rated Output Power | 15 kW (20 HP) |
| Rated Output Current | 31 A |
| Input Voltage | 3‑Phase 380–480 V AC |
| Input Frequency | 47–63 Hz |
| Voltage Tolerance | −10% / +10% of nominal |
| Output Frequency Range | 0–400 Hz |
| Control Modes | V/Hz, Sensorless Vector Control |
| Overload Capacity | 150% for 60 seconds, 200% for 3 seconds (typical for Frame B) |
| Cooling Method | Forced Air (Integrated Fan) |
| Maximum Ambient Temperature | 50 °C (122 °F) |
| Storage Temperature | −40 °C to +70 °C (−40 °F to +158 °F) |
| Maximum Altitude (No Derating) | 1000 m (3300 ft) |
| Relative Humidity | 5–95% non‑condensing |
| Vibration Resistance | 0.152 mm displacement (1 G peak) |
| Shock Resistance | 15 G peak, 11 ms duration |
| Control Power Input | 115 V AC |
| Standard I/O | 2 Configurable Analog Inputs (Isolated); Digital I/O (115 V AC / 24 V AC/DC / TTL) |
| Communication | Base Unit: None (Optional via GM Series Adapters) |
| Language Module | English (EN) |
| Mounting | Vertical Panel Mount |
| Approximate Weight | 22.68 kg (50.00 lbs) |
| Compliance | UL, CSA, EN, IEC, VDE |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
