1 PCS used NED NUCLi7300-M84.5-00-100-S7 Line Scan Camera #LYQ007
1 PCS used NED NUCLi7300-M84.5-00-100-S7 Line Scan Camera #LYQ007
| Parameter | Specification |
|---|---|
| Model | NUCLi7300-M84.5-00-100-S7 (NUCLi7370AT6) |
| Product Type | Color Line Scan Camera (Rainbow Series, Trilinear CCD) |
| Resolution | 7300 × 3 pixels |
| Pixel Size | 10 × 10 µm |
| Sensor Length | 73 mm |
| Spectral Responsivity | 400–700 nm (Peak: R=610, G=540, B=460 nm) |
| Data Rate | 140 MHz (6‑tap output) / 70 MHz (3‑tap output) |
| Bit Depth | 24‑bit RGB, 30‑bit RGB |
| Clock Speed | 70 MHz |
| Taps | 3, 6 |
| Max Line Rate | 17.5 kHz (6‑tap) / 11.3 kHz (3‑tap) / 8.7 kHz (Pseudo‑exposure) |
| Saturation Exposure | 0.0384 lx·s (Min Gain, Daylight Fluorescent) |
| Responsivity | 130 V/(lx·s) (Analog 5V Conversion, Visible 400–700 nm) |
| Gain Range | Analog + Digital; Recommended: ×1–×2.5; Max: ×5 |
| Digital Offset | 8‑bit: 0–15 DN (16 steps); 10‑bit: 0–60 DN (16 steps) |
| PRNU | Typ. 6% (uncorrected, min gain); Typ. 2% (corrected, min gain) |
| Random Noise | Typ. 30 DN (peak, min gain) |
| Lens Mount | M84.5 |
| Dimensions (W×H×D) | 108 × 150 × 60.1 mm |
| Weight | 800 g (body without mount) |
| Interface | Camera Link (Base/Medium/Full Configurations) |
| Connectors | 2× MDR26 (Camera Link); 1× Hirose HR10G (6‑pin, Power) |
| Power Supply | DC 12–15 V (±5%) |
| Current Consumption | 900 mA |
| Operating Temp | 0–50 °C (no condensation) |
| Key Features | High‑speed readout; Gain/offset control; Flat‑field correction; Auto white balance; Pseudo‑exposure control |
