1 PCS used TOSHIBA TELI BU505MCF Color Industrial Camera #LYQ007
1 PCS used TOSHIBA TELI BU505MCF Color Industrial Camera #LYQ007
| Parameter | Specification |
|---|---|
| Model | BU505MCF |
| Interface | USB 5Gbps (USB3.1 Gen1, SuperSpeed only) |
| Effective Pixels | 5.01 Megapixels |
| Image Sensor | CMOS (Sony IMX250LQR) |
| Resolution | 2,448 (H) × 2,048 (V) |
| Frame Rate | 75 fps (Bayer 8-bit) |
| Pixel Size | 3.45 μm × 3.45 μm |
| Sensor Format | 2/3-inch |
| Scanning Area | 8.45 mm (H) × 7.07 mm (V) |
| Aspect Ratio | 6:5 |
| Scanning Mode | Progressive |
| Shutter Type | Global Shutter (Manual / Random Trigger) |
| Trigger Modes | External / Software; Edge / Level / Bulk (255 times) |
| Sequential Shutter | Max. 16 entries |
| Exposure Time | Manual: 1.08 μs ~ 14.44 μs (Short ON), 30 μs ~ 16 s (Short OFF)
|
| Synchronization | Internal / Bus (USB) |
| Color Filter | On-chip RGB primary mosaic; IR Cut Filter |
| Sensitivity | 3,300 lx (F5.6, 1/75 s) |
| Min. Illumination | 7 lx (F1.4, Gain +24 dB, Video 50%) |
| Gain | Manual: 0 ~ +24 dB |
| Black Level | -25% ~ +25% |
| Gamma | 0.45 ~ 1.0; 12-bit In / 12-bit Out |
| White Balance | Manual / One-push |
| Image Buffer | 256 MB (53 frames at full resolution) |
| Output Formats | RGB 24-bit, BGR 24-bit, YUV422 16-bit, YUV411 12-bit,
|
| Readout Modes | All pixel, Scalable, Binning, Decimation, Mirror, Flip |
| Trigger Input | Low: 0–0.5 V; High: 2–24 V; Min. pulse: 50 μs |
| Power Supply | DC 5 V ±5% |
| Power Consumption | Max. 3.6 W |
| Lens Mount | C-mount |
| Dimensions | 29 (W) × 29 (H) × 16 (D) mm (excl. protrusions) |
| Weight | Approx. 33 g |
| Operating Temp | 0 °C ~ 40 °C (case surface < 50 °C) |
| Operating Humidity | 10% ~ 90% (non-condensing) |
| Compliance | CE, FCC, RoHS, WEEE, USB3 Vision, GenICam, IIDC2 |
