1 PCS used EVERRED ER-400CL Industrial Camera #LYQ007
1 PCS used EVERRED ER-400CL Industrial Camera #LYQ007
| Parameter | Value |
|---|---|
| Model | ER-400CL |
| Camera Type | High‑performance 3‑CMOS RGB line scan camera |
| Sensor | 3 × CMOS (R/G/B) |
| Effective Pixels | 3 × 4096 pixels (H) |
| Pixel Size | 7.0 μm (H) × 7.0 μm (V) |
| Sensor Scanning Width | 28.672 mm |
| Pixel Clock | 80 MHz |
| Max Line Rate | 16,180 lines/sec (16.18 kHz) |
| Shutter Type | Global shutter |
| Exposure Time | 60 μs to 14.9 ms (12.5 ns increments) |
| Output Format | 3 × 8‑bit or 3 × 10‑bit via Camera Link |
| Interface | Camera Link (CL) |
| Lens Mount | M52 (standard); Nikon F‑mount (factory option) |
| Trigger Modes | No‑shutter, Shutter‑select, Pulse Width Control (PWC) |
| Synchronization | Internal crystal or external trigger |
| Gain Control | Analog: 0 dB to +6 dB; Digital: –3 dB to +14 dB (R/G/B) |
| White Balance | Manual, fixed, one‑push; 4000 K to 9000 K |
| Correction | Flat‑field, shading, pixel‑by‑pixel compensation |
| Power Supply | DC 12 V ±10% to 24 V +10% |
| Power Consumption | Typical 5.4 W; Max 5.8 W |
| Dimensions (W×H×D) | 90 × 90 × 90 mm (excl. connectors/lens) |
| Weight | Approx. 1.2 kg |
| Operating Temp. | –5°C to +45°C, 20–80% RH (non‑condensing) |
| Storage Temp. | –25°C to +60°C, 20–80% RH (non‑condensing) |
| Vibration | 3G (20–200 Hz, XYZ) |
| Shock | 50G |
| Compliance | FCC Part 15 Class B, CE, RoHS |
