Parameter Category    Details
Model Identification    PowerFlex 700 AC Drive
Frame Size: 7
Product Line: 20B
Part Number: 20BC105A0ANNANC0
Power Ratings    Input Voltage: 400 V AC, 3‑phase
Input Frequency: 50/60 Hz
Output Current: 105 A
Output Power: 55 kW (75 hp) @ 400 V (normal duty); 45 kW (60 hp) @ 400 V (heavy duty)
Voltage Class: Low Voltage (≤ 600 V AC)
Control Modes    V/Hz, Sensorless Vector, Vector Control (with optional encoder feedback), Torque Control, Built‑in PID Control
Communication & Control    Communication: No built‑in communication module (slot empty)
Control: Vector Control Cassette
I/O Voltage: 24 V DC
CE Filter: Yes
CM Choke: Yes
Dynamic Braking Transistor: Yes
Internal Braking Resistor: No
Operator Interface: Blank Cover
Feedback: None (open‑loop control)
Protection & Installation    IP Rating: IP20 (front face, open type)
NEMA Rating: NEMA/UL Type 1 (when installed with optional enclosure)
Cooling Method: Forced Air Cooling
Mounting: Panel Mount
Environmental Limits    Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F); derate above 40 °C
Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
Humidity: 5% to 95% RH, non‑condensing
Altitude: Up to 1000 m (3300 ft) without derating; derate 1% per 100 m above 1000 m
Safety & Compliance    Safety Features: Overcurrent, Overvoltage, Undervoltage, Thermal Overload, Short Circuit Protection
Certifications: UL, cUL, CE, CSA, RoHS Compliant

1  .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
 Including : frequency converter, servo driver, servo motor,   data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial   computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
 3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please    contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
