Parameter Category    Details
Power Rating    - Nominal Input Voltage: 400 V AC, 3‑Phase
- Input Frequency: 50/60 Hz
- Nominal Output Current: 140 A
- Output Power: 75 kW (100 HP) at 400 V AC (normal duty)
- Voltage Class: Low Voltage (≤ 690 V AC)
Core Features    - Control Mode: V/Hz, Sensorless Vector, Closed‑Loop Vector (optional with encoder feedback)
- HMI: No built‑in LCD keypad (basic keypad only)
- Conformal Coating: Included
- EMC Filter: None (key difference from -NACC0)
- Brake IGBT: Included
Protection    Overcurrent, Overvoltage, Undervoltage, Thermal Overload (drive/motor), Short Circuit, Ground Fault; IP20/NEMA 1 enclosure
I/O & Communication    - Digital I/O: 8 inputs, 3 outputs
- Analog I/O: 2 inputs, 2 outputs
- Communication: No embedded module (supports DeviceNet/EtherNet/IP/ControlNet via slot)
Mechanical & Cooling    - Cooling: Forced Air
- Mounting: Floor/Rack
- Frame Size: 5

Operating Conditions    - Temperature: -10°C to +40°C (14°F to 104°F) (derate 1% per °C above 40°C up to 50°C)
- Humidity: 5% – 95% non‑condensing
- Altitude: ≤1000 m (3280 ft) (derate 1% per 100 m above 1000 m)
Compliance    CE, UL, CSA, RoHS compliant

1.Our company specializes in automation industrial control accessories. We have more than 100,000 products.
?Including : frequency converter, servo driver, servo motor,data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial?? computer,encoder...etc
2.We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over the world.
3.We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store may not accurate,before purchasing please contact us to provide you with exactly quote and real pictures.
4. If you can not find the product which you need in our store, please contact us. We will check it for you.
