1pc used Tektronix E1 Control Board 7KK1200-2PE11#LYQ007
1pc used Tektronix E1 Control Board 7KK1200-2PE11#LYQ007
1pc used Tektronix E1 Control Board 7KK1200-2PE11#LYQ007
Part Number: 7KK1200-2PE11; Model: E1; Product Name: Tektronix E1 Industrial Control Board; Product Series: Tektronix E Series, Precision Relay Protection & Test Control Board for Power System Test Equipment
Brand: Tektronix (Tektronix, Inc., a global leader in test, measurement, and monitoring solutions, specializing in electronic test equipment, signal processing modules, and industrial control boards. The brand is renowned for high-precision, reliable products tailored to aerospace, defense, power system, and industrial automation industries worldwide, delivering cutting-edge performance for critical power test and control tasks.)
Product Status: Industrial-Grade Original Equipment (Factory Calibrated, 100% Functional, RoHS Compliant); Product Category: Rack-Mounted Industrial Control Board, engineered as a core control unit for Tektronix relay protection test systems, enabling precise signal generation control, test sequence management, and data interaction between test modules and host equipment.
Core Application: Widely integrated in Tektronix microcomputer relay protection testers, power system fault simulation systems, multi-channel electrical parameter test platforms, and power grid equipment verification systems. Specifically suitable for power system test scenarios requiring stable AC/DC signal control, high-precision phase adjustment, and seamless integration with Tektronix power test instruments and data acquisition modules.
Core Features: Advanced signal control circuitry for high-precision AC/DC signal regulation; Built-in multi-channel I/O interfaces for relay contact detection and control; Industrial-grade components ensuring low noise and high stability in power test environments; Comprehensive self-diagnostic functions for quick fault localization; Support for Tektronix proprietary control protocols and SCPI standard commands; Compact rack-mount design for space-saving system integration; Compliance with international power test equipment safety and EMC standards.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Processing & Signal Control Parameters
Processor: 32-bit High-Performance RISC Processor (1.0 GHz), Optimized for Power Signal Control & Real-Time Test Sequence Processing; Instruction Execution Speed: ≥ 1.8 MIPS for Logic Control, ≥ 1.0 MIPS for Floating-Point Signal Calculation;
Signal Control Precision: AC Current/Voltage: ±0.1% Full Scale (FS) for 0.5A~120V range, ±10mV/10mA resolution; DC Current/Voltage: ±0.5% FS for ±1A~±150V range; Phase Adjustment Range: 0°~360°, Phase Precision: ±0.2°, Phase Resolution: 0.1°; Frequency Range: 1Hz~2000Hz, Frequency Precision: ±0.001Hz (1Hz~100Hz), ±0.01Hz (100Hz~2000Hz), Frequency Resolution: 1mHz;
Memory Configuration: RAM: 256 MB DDR3 SDRAM (For Real-Time Data Processing and Test Sequence Storage), Flash Memory: 16 MB (For System Firmware and Configuration Parameter Storage); Battery Backup: 3.6V Lithium Battery, Backup Time: ≥ 5 Years (For Configuration Data and Test Sequence Retention During Power Off); Harmonic Output: Supports 2~40th Harmonic Output with Adjustable Amplitude.
2.2 Communication & Interface Parameters
Ethernet Interfaces: 1×Gigabit Ethernet Port (RJ45 Connector), Supports TCP/IP, UDP, and Tektronix Proprietary Control Protocols, Data Transfer Rate: 10/100/1000 Mbps (Auto-Negotiation), Latency: ≤8ms;
Serial Interfaces: 1×RS-232 Port (DB9 Female Connector, For Local Configuration and Debugging), 1×RS-485 Port (Optically Isolated, For Multi-Device Daisy-Chain Connection), Baud Rate: 1200 bps ~ 115200 bps (Configurable);
I/O Interfaces: 16×Independent Switch Input Channels (Compatible with Dry/Wet Contacts, Auto-Polarity Recognition), 8×Programmable Switch Output Channels (Dry Contacts, 250VAC/DC, 0.5A Capacity); USB Interface: 1×USB 2.0 Port (Type B, For Firmware Update and Local Test Data Transfer);
Supported Protocols: Tektronix Proprietary Control Protocol, Modbus TCP/IP, SCPI (Standard Commands for Programmable Instruments), Compatible with Third-Party Power Test Equipment Supporting SCPI Protocol.
