Parameter Category    Details
Power Rating    - Nominal Input Voltage：480 VAC, 3-phase
- Nominal Output Current：125 A
- Nominal Output Power：75 kW (100 HP) at 480 VAC
- Voltage Class：480V Class
Input Specifications    - Input Voltage Range：380 - 480 VAC, 3-phase
- Input Frequency Range：50/60 Hz ± 5%
- Input Current：134 A (at full load)
- Power Factor Correction：Active power factor correction (optional, depending on configuration)
- Protection：Input phase loss protection, overvoltage/undervoltage protection
Output Specifications    - Output Voltage Range：0 - Input voltage
- Output Frequency Range：0 - 400 Hz
- Output Resolution：0.01 Hz
- Control Modes：V/Hz control, sensorless vector control, closed-loop vector control (optional with encoder feedback)
- Torque Control：Torque mode operation available in vector control modes
- Overload Capacity：150% of rated current for 60 seconds, 200% for 3 seconds
Mechanical Specifications    - Enclosure Type：NEMA 1 / IP21 (standard), optional NEMA 12 / IP54
- Cooling Method：Forced air cooling

- Mounting Type：Floor-mounted or wall-mounted (depending on enclosure)
Control & Communication    - Embedded Communication：None (base model; communication cards optional: DeviceNet, Ethernet/IP, Profibus DP, etc.)
- I/O Configuration：- Digital Inputs: 6 configurable inputs
- Digital Outputs: 2 relay outputs
- Analog Inputs: 2 (0-10 VDC, 4-20 mA)
- Analog Outputs: 1 (0-10 VDC, 4-20 mA)
- Programming Interface：Keypad (local), USB port, Allen-Bradley DriveExplorer/DriveExecutive software
Environmental Specifications    - Operating Temperature：0 °C to 40 °C (32 °F to 104 °F) without derating; derate by 2% per °C above 40 °C up to 50 °C
- Storage Temperature：-40 °C to 70 °C (-40 °F to 158 °F)
- Humidity：5% to 95% non-condensing
- Altitude：Up to 1000 m (3300 ft) without derating; derate by 1% per 100 m above 1000 m
Safety Features    - Safety Stop：Optional Safe Torque Off (STO) function
- Short Circuit Protection：Internal short circuit protection, I²t thermal protection
- Ground Fault Protection：Built-in ground fault detection
