1 pc new COMSOFT DF-Profi II-PCI (G619301) card #LYQ007
1 pc new COMSOFT DF-Profi II-PCI (G619301) card #LYQ007
| Parameter | Details |
|---|---|
| Product Model | DF-Profi II-PCI, G619301 |
| Product Type | High-performance PROFIBUS DP/DPV1 Interface Card |
| Processor | Net+ARM 40, 33 MHz |
| PROFIBUS Controller | ASPC2, 48 MHz |
| Memory | 1 MByte SRAM; 2 MByte Flash (non-volatile) |
| PCI Interface | 32-bit PCI, 5V and 3.3V compatible, PLX-compliant |
| PROFIBUS Interface | 1 × Sub-D 9-pin (RS485, electrically isolated) |
| PROFIBUS Modes | DPV0 Class 1 Master, DPV1 Class 2 Master, DP Slave |
| Baud Rates | 9.6 kbit/s – 12 Mbit/s (auto-baud detection) |
| Isolation Voltage | 500 VDC |
| Power Consumption | +5V / max. 1100 mA |
| Process Data Exchange | Up to 8 KByte process image; approx. 1 ms cycle time (3 KByte data) |
| Special Features | Hardware Watchdog (physical bus disconnect); Time-stamped process data (1 ms resolution); Redundancy support |
| Operating Systems | Windows 2000/XP, Linux (SUSE, RedHat, Fedora), LabVIEW RT |
| Temperature Range | 0 °C – 55 °C (operation) |
| Dimensions | Standard PCI format (175 mm × 107 mm) |
| Standards | PROFIBUS EN 50170; CE compliant |
| Additional Software | COMSOFT CONFIGURATOR II; OPC Server; FDT 1.2 DTM; LabVIEW VISA Driver |
1.Our company specializes in automation industrial control accessories. We have more than 100,000 products.
?Including : frequency converter, servo driver, servo motor,data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial?? computer,encoder...etc
2.We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over the world.
3.We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store may not accurate,before purchasing please contact us to provide you with exactly quote and real pictures.
4. If you can not find the product which you need in our store, please contact us. We will check it for you.
