Part Number: JC-120MC-R; Product Name: Jetter JC-120MC-R Control Module; Product Series: JC Series, High-Performance Industrial Control Module
Brand: Jetter (Jetter AG, a German-based leading provider of industrial automation solutions, specializing in high-precision control systems, motion controllers, and custom automation modules. Renowned for reliability and compatibility in harsh industrial environments, serving automotive, packaging, material handling, and process industries globally.)
Product Status: Industrial-Grade Original Component (Factory Calibrated, In-Stock); Product Category: Multi-Functional Industrial Control Module, designed for real-time logic control, motion control, and process monitoring, featuring seamless integration with Jetter automation systems and third-party devices.
Core Application: Widely applied in automated production lines, packaging machinery, printing equipment, material handling systems, and precision assembly stations. Capable of realizing complex logic control, sequential control, and distributed control tasks, suitable for scenarios requiring high real-time performance, stable operation, and flexible expansion in harsh industrial conditions.
Core Features: High-speed 32-bit industrial processor for real-time data processing; Support for multiple control modes (logic control, motion control, process control); Rich I/O interfaces for flexible connection with sensors, actuators, and other devices; Built-in industrial communication protocols for seamless system integration; Industrial-grade hardware design with anti-interference and protection functions; Compatible with Jetter JX Works programming software; Compact structure for space-saving installation; Comprehensive fault diagnosis and status monitoring functions.
2. Core Performance Specifications (Ta = 25℃, Unless Otherwise Specified)
2.1 Electrical & Control Performance
Power Supply: DC 24V (±10% Fluctuation), Rated Current: 0.8A (Typical), 1.5A (Peak); Power Consumption: ≤18W (Normal Operation), ≤25W (Full Load).
Processor: Industrial-Grade 32-Bit RISC Processor, Clock Frequency: 400MHz; Memory: 512KB Flash Memory (For Program Storage), 128KB RAM (For Real-Time Data Processing), Support for External Memory Expansion via SD Card Slot.
Control Performance: Logic Execution Speed: ≤0.1μs per Boolean Instruction; Motion Control: Support for 2-Axis Interpolation (Linear/Circular), Positioning Accuracy: ±0.01mm (With Encoder Feedback); Response Time: ≤1ms (Digital Input/Output Signal Processing).
Encoder Interface: 2×Incremental Encoder Inputs (Differential Signal, 5V DC), Maximum Encoder Frequency: 1MHz, Support for Encoder Resolution Up to 1,000,000 Pulses/Rev.
2.2 Communication & I/O Parameters
Communication Ports: 1×Ethernet Port (10/100Mbps, Support for TCP/IP, Modbus TCP, Ethernet/IP Protocols), 1×RS485 Port (Optically Isolated, Support for Modbus RTU Protocol), 1×CANopen Port (For Connection with CANopen Devices).
Communication Parameters: Baud Rate (RS485): 9600-115200 bps (Adjustable), Data Bits: 8, Stop Bits: 1, Parity: None/Even/Odd (Selectable); Ethernet Transmission Delay: ≤10ms (Typical).
Digital I/O: 16×Digital Inputs (DI, 24V DC, Optically Isolated, Response Time ≤10μs), 8×Digital Outputs (DO, 24V DC, Optically Isolated, Max 0.5A Per Channel, Support for Sink/Source Output).
Analog I/O: 4×Analog Inputs (AI, 0-10V DC / 4-20mA, 12-Bit Resolution, Accuracy ±0.1%), 2×Analog Outputs (AO, 0-10V DC / 4-20mA, 12-Bit Resolution, Load Capacity ≥500Ω).
