1PC used 100% tested PN-200923 the gate driver board of Allen-Bradley (AB) PowerFlex 753 series low-voltage AC drives #QYM001 J1688
1PC used 100% tested PN-200923 the gate driver board of Allen-Bradley (AB) PowerFlex 753 series low-voltage AC drives #QYM001 J1688
| Parameter Category | Core Details |
|---|---|
| Compatible Drives | PowerFlex 753 series low-voltage AC drives; typical power range 15–75kW (subject to main drive model) |
| Core Functions | IGBT gate signal generation/amplification, overcurrent/overvoltage protection for IGBTs, desaturation detection, active clamping, fault signal feedback to the main control board, drive enable/disable control |
| Drive Signal Specifications | - Channel count: 6 channels (3-phase IGBTs, each with high/low side drive)
|
| Protection Functions | IGBT short-circuit protection (response time ≤ 1μs), over-temperature protection (built-in NTC thermistor), undervoltage lockout (UVLO) for drive power, ESD protection (compliant with IEC 61000-4-2) |
| Power Supply | Drive power: DC 24V (from drive auxiliary power); Power consumption ≤ 8W |
| Environment & Structure | Operating temperature: -10–60℃; Storage temperature: -40–85℃; PCB material: FR-4 with conformal coating; Protection class: IP20 (cabinet mounting); Relative humidity: 5%–95% (non-condensing) |
| Physical Specifications | Dimensions: approx. 110×80×25mm; Weight: approx. 120g; PCB flame retardant rating: 94V-0 |
