Parameter Category    Details
Power Ratings    - Nominal Input Voltage：480 V AC, 3‑Phase
- Nominal Output Current：140 A
- Nominal Output Power：100 HP (75 kW) Normal Duty, 75 HP (55 kW) Heavy Duty at 480 V
- Input Frequency：50/60 Hz, ± 5%
Key Configuration    - Brake：Brake IGBT installed (no internal brake resistor)
- Control & I/O：Vector control, 24V DC I/O
- Feedback：None
- HIM：No HIM (blank plate)
- Comm Slot：None (supports optional modules like DeviceNet, EtherNet/IP)
- EMI Filter：CE filter & CM choke included
Control Modes    - V/Hz (Voltage/Frequency)
- Sensorless Vector Control
- Vector Control (with optional encoder feedback)
Input Specifications    - Voltage Tolerance：323‑528 V AC (3‑Phase)
- Input Current：135 A (full load)
- Power Factor：> 0.95 (full load, 60 Hz)
Output Specifications    - Output Voltage：0 to input voltage
- Output Frequency：0 to 400 Hz
- Overload Capacity：150% for 60 seconds, 200% for 3 seconds
Protection Features    - Overcurrent, overvoltage/undervoltage, overtemperature
- Short circuit, ground fault, motor thermal protection
- Instantaneous current limit: 220‑300% of rated current
Mechanical & Environmental    - Enclosure：IP20/NEMA 1, with Conformal Coat
- Cooling：Forced air

- Operating Temperature：0‑40 °C (derate above 40 °C)
- Altitude：Up to 1000 m (no derating); 1% derate per 100 m above 1000 m
Compliance    UL Listed, CSA Certified, CE Marked, RoHS Compliant
