1 PCS new Azbil AUR890G630 Burner Controller #LYQ007
1 PCS new Azbil AUR890G630 Burner Controller #LYQ007
| Item | Specification |
|---|---|
| Model | AUR890G630 |
| Type | Burner Controller (for batch‑operated combustion systems) |
| Power Supply | 200 V AC (50/60 Hz) |
| Allowable Voltage | 85–110% of rated supply |
| Power Consumption | ≤ 10 W |
| Lock‑Out Timing | 13.5 ± 1.5 s |
| Flame Response Time | 3 ± 1 s (UV sensor AUD100/110/120 series) |
| Ignition Wait Time | 3 ± 0.3 s |
| Main Burner Combustion Wait Time | 0.4 s |
| False Flame Detection Time | 15 s |
| Reset Timing | ≥ 1 s (manual RESET or contact reset input) |
| Compatible Flame Detectors | AUD100 / 110 / 120 series UV sensors |
| Flame Detection Level | Establishment: 1.5–4.5 V DC; Flame‑out: 0.2–0.6 V DC |
| Flame Voltage Output | 0.2–4.5 V DC; recommended ≥ 2 V DC |
| Contact Ratings | Ignition transformer: 360 VA; Pilot valve: 200 VA; Main valve: 200 VA; Alarm: 75 VA |
| Dielectric Strength | 1500 V AC for 1 min, or 1800 V AC for 1 s (between terminals and ground) |
| Insulation Resistance | ≥ 50 MΩ (500 V DC megger) |
| Operating Ambient | Temperature: −20 to +60 °C; Humidity: 10–90% RH (no condensation) |
| Storage Ambient | Temperature: −20 to +70 °C; Humidity: 5–95% RH (no condensation) |
| Vibration (Operating) | 0–3.2 m/s² (10–150 Hz, 1 octave/min, 10 cycles) |
| Shock (Operating) | 0–9.8 m/s² |
| Protective Structure | IP40 (with sideboard); IP10 (without) |
| Overvoltage Category | II |
| Pollution Degree | PD2 |
| Dimensions (with BC‑R05A100 sub‑base) | W95 × H105 × D110 mm |
| Weight | Approx. 600 g (including sub‑base) |
| Service Life | 10 years (8 h/day) or 100,000 start/stop cycles (25 °C, rated voltage) |
| Standards | UL 60730‑2‑5, FM7610 |
| Replacement For | RA890G1278X2 |
