1 PCS new SICK WTB16P-1H161220A00 (1218820) sensor#LYQ007
1 PCS new SICK WTB16P-1H161220A00 (1218820) sensor#LYQ007
| Parameter | Specification |
|---|---|
| Model | WTB16P-1H161220A00 |
| Order No. | 1218820 |
| Sensor Type | Photoelectric proximity sensor, diffuse with background suppression (BGS), narrowbeam |
| Sensing Range | Min. sensing distance: 10 mm
|
| Reference Object | Standard white (90% reflectance, DIN 5033) |
| Light Source | PinPoint LED, visible red light |
| Spot Shape | Circular, ø 3 mm at 200 mm distance |
| Supply Voltage | DC 10 V ... 30 V |
| Output | Push-pull (PNP/NPN), light/dark selectable |
| Response Time | ≤ 1.25 ms |
| Switching Frequency | 400 Hz |
| Max. Output Current | 100 mA |
| Connection | 4-wire cable, 2 m, M12 male connector |
| Housing Material | VISTAL® |
| Dimensions (W x H x D) | 20 mm x 55.7 mm x 42 mm |
| Protection Class | IP66, IP67, IP69 (EN 60529) |
| Operating Temperature | –40 °C ... +60 °CSICK |
| Storage Temperature | –40 °C ... +75 °CSICK |
| Communication | IO-Link v1.1 |
| Adjustment | Teach-in button, potentiometer, Teach-Turn |
| Certifications | CE, cULus, ECOLAB |
