1 PCS new RUGGEDCOM I802-M-T-FX06 Switch #LYQ007
1 PCS new RUGGEDCOM I802-M-T-FX06 Switch #LYQ007
| Parameter | Value |
|---|---|
| Product Type | Compact Fully Managed Industrial Layer 2 Ethernet Switch |
| Ordering Key (M-T-FX06) | M=Managed, T=6×10/100BASE-TX, FX06=1×100BASE-FX (LC) |
| Siemens Article No. | 6GK6008-2AS20-0UT0-Z (equivalent config) |
| Fixed Ethernet Ports | 6×10/100BASE-TX (RJ45, Auto MDI/MDI-X, Full/Half-Duplex) |
| Fixed Fiber Ports | 1×100BASE-FX (LC, Multi-Mode/Single-Mode configurable) |
| Switching Capacity | 10 Gbps |
| Packet Forwarding Rate | 7.48 Mpps (wire-speed for all ports) |
| MAC Address Table | 8,192 entries |
| VLAN Support | IEEE 802.1Q (4,094 VLANs), GVRP |
| Spanning Tree | IEEE 802.1D (STP), 802.1w (RSTP), 802.1s (MSTP) |
| Power Input | 24 VDC (10–36 VDC) dual redundant inputs, compression fit |
| Power Consumption | Max. 15 W |
| Operating Temperature | Extended: -40 °C to +85 °C |
| Storage Temperature | -40 °C to +85 °C |
| Enclosure | Galvanized steel, IP40 |
| Shock & Vibration | IEC 60068-2-27 (shock), IEC 60068-2-6 (vibration) |
| EMC Immunity | IEC 61000-6-2 (industrial), IEC 61000-4-2/3/4/5/6 (enhanced) |
| Safety Certification | CSA/UL 60950-1, IEC 60950-1 |
| Industry Compliance | IEC 61850-3, IEEE 1613 (substation automation) |
| Management Interface | 1×RS-232 (DB9), Telnet, SSH, HTTP(S), SNMPv1/v2c/v3 |
| Security Features | 802.1X, MAC-based port security, RADIUS, SSH/SSL (128-bit), SNMPv3 56-bit encryption |
| Dimensions (W×H×D) | 120 mm × 100 mm × 30 mm |
| Weight | Approx. 1 kg |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
