1 PCS new Elmo Driver G-DCTR012/400-AMBA #LYQ007
1 PCS new Elmo Driver G-DCTR012/400-AMBA #LYQ007
|
Item
|
Specification
|
|
Model Number
|
G-DCTR012/400-AMBA
|
|
Product Name
|
Elmo Industrial Servo Driver
|
|
Product Series
|
G-DCTR Series, High-Power Density Servo Driver with AMBA Interface
|
|
Brand
|
Elmo Motion Control
|
|
Product Status
|
Industrial-Grade Original Equipment, RoHS 3.0 Compliant, CE Certified, UL Listed, IP20 Protection Class
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Notes
|
|
Supply Voltage (AC)
|
320
|
400
|
480
|
V AC (3-Phase)
|
Stable AC input, frequency 50/60 Hz ± 10%, ripple voltage ≤ 3%
|
|
DC Bus Voltage
|
450
|
560
|
670
|
V DC
|
Automatic voltage stabilization, overvoltage/undervoltage protection triggered at 700V/400V
|
|
Continuous Output Current
|
10
|
12
|
14
|
A RMS
|
Continuous operation at 25℃ ambient temperature, derating 8% per 10℃ above 45℃
|
|
Peak Output Current
|
24
|
28
|
32
|
A RMS
|
Duration ≤ 2 seconds, duty cycle ≤ 10%, for short-term high-load acceleration/deceleration
|
|
Output Power
|
5.5
|
7.5
|
9.0
|
kW
|
Depends on supply voltage and output current, efficiency ≥ 95% (full load, 400V AC input)
|
|
Control Mode
|
-
|
Current / Velocity / Position / Torque / Cascaded Control
|
-
|
-
|
Software-configurable via Elmo Studio, seamless mode switching, support advanced trajectory planning
|
|
Current Control Bandwidth
|
5
|
10
|
15
|
kHz
|
High bandwidth for fast current response, low torque ripple (< 0.5% at rated torque), stable operation
|
|
Velocity Control Range
|
0.01
|
2000
|
8000
|
RPM
|
Precision velocity regulation, error ≤ 0.01% of set value, support speed smoothing and jerk limitation
|
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Notes
|
|
Position Control Resolution
|
0.0001
|
0.001
|
0.01
|
Counts
|
Depends on encoder resolution, support 18-bit to 26-bit absolute/incremental encoder input
|
|
Maximum Velocity Command
|
1
|
3000
|
12000
|
RPM
|
Software-limited, compatible with high-speed servo motors, support real-time speed feedback
|
|
Acceleration / Deceleration
|
500
|
10000
|
50000
|
RPM/s
|
Adjustable via Elmo Studio, support S-curve and trapezoidal acceleration/deceleration, jerk adjustable
|
|
Encoder Input
|
2048
|
8192
|
65536
|
Lines/rev
|
Support incremental/absolute encoders, differential signal input, anti-interference design, 5V/12V differential output
|
|
Control Cycle
|
0.02
|
0.1
|
1
|
ms
|
Real-time motion control cycle, software-configurable for different precision and response requirements
|
|
Integrated IO Channels
|
8
|
12
|
16
|
Channels
|
8 Digital Inputs (24V DC) + 4 Digital Outputs (24V DC, 1A per channel), optically isolated, configurable function
|
|
Analog Input (Optional)
|
-
|
4~20mA / 0~10V
|
-
|
-
|
16-bit resolution, for speed/torque command input, configurable range and scaling
|
