1 PCS used FAST FV-aligner FV2330-W7e Vision Positioning System Controller #LYQ007
1 PCS used FAST FV-aligner FV2330-W7e Vision Positioning System Controller #LYQ007
1 PCS used FAST FV-aligner FV2330-W7e Vision Positioning System Controller #LYQ007
1. General Specifications (Original Factory Standard)
|
Parameter
|
Specification
|
Unit
|
Official Notes
|
|
Product Name
|
FV-aligner Vision Positioning System Controller
|
-
|
Original FAST factory product, FV2330-W7e model, specialized for high-precision vision positioning, alignment and control in industrial automation scenarios
|
|
Model Number
|
FV2330-W7e
|
-
|
Unique model code for FAST FV-aligner series vision positioning controller, consistent with factory calibration, quality standards and technical specifications
|
|
Brand & Manufacturer
|
FAST Automation
|
-
|
Complies with FAST strict industrial automation control equipment standards, ensuring high positioning precision, stable performance and long service life
|
2. Vision Positioning Performance Specifications
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Official Notes
|
|
Positioning Precision
|
-
|
±0.001
|
±0.003
|
mm
|
High positioning precision, meeting the requirements of industrial fine alignment and positioning scenarios (e.g., electronic component assembly, precision machining)
|
|
Repeat Positioning Accuracy
|
≤0.0005
|
0.0008
|
≤0.001
|
mm
|
Excellent repeatability, ensuring consistent positioning accuracy in long-term continuous operation, reducing production errors
|
|
Positioning Speed
|
≥500
|
600
|
800
|
Points/Min
|
Fast positioning response, adapting to high-speed industrial automation production lines, improving production efficiency
|
|
Alignment Response Time
|
≤10
|
15
|
≤20
|
ms
|
Instant alignment response, realizing real-time adjustment according to vision feedback, ensuring alignment accuracy and efficiency
|
|
Vision Recognition Resolution
|
1280×720
|
1920×1080
|
2560×1440
|
Pixel
|
Compatible with multiple resolution vision cameras, capturing clear positioning marks, ensuring positioning accuracy
|
|
Recognition Success Rate
|
≥99.8
|
99.9
|
-
|
%
|
High recognition stability, adapting to slight changes in industrial lighting and scene environment, reducing misalignment rate
|
3. Electrical Performance Specifications (Ta = 25℃, RH = 60%, Standard Working Conditions)
|
Parameter
|
Minimum
|
Typical
|
Maximum
|
Unit
|
Official Notes
|
|
Input Voltage Range (DC)
|
18
|
24
|
30
|
VDC
|
Wide voltage input, anti-voltage fluctuation, compatible with standard industrial 24VDC power supply system
|
|
Operating Current (DC, 24VDC)
|
0.5
|
0.8
|
1.2
|
A
|
Low power consumption design, supporting long-term continuous operation under full load without performance degradation
|
|
Signal Input Voltage Range
|
0
|
5
|
24
|
VDC
|
Compatible with TTL and industrial-level input signals, anti-interference, ensuring accurate signal collection from vision cameras and sensors
|
|
Signal Output Voltage Range
|
0
|
5
|
24
|
VDC
|
Stable signal output, supporting control signal transmission to motion actuators, solenoid valves and other peripheral equipment
|
|
Insulation Resistance
|
100
|
500
|
-
|
MΩ
|
High insulation performance, effectively preventing short circuit and leakage, ensuring equipment and personnel safety
|
|
Power Supply Ripple
|
-
|
≤50
|
≤100
|
mVpp
|
Low power supply ripple, ensuring stable operation of internal control circuits and vision processing modules
|
