1 PCS used Brooks CMCAP1134AR Capacitance Manometer #LYQ007
1 PCS used Brooks CMCAP1134AR Capacitance Manometer #LYQ007
| Parameter | Value |
|---|---|
| Model | CMCAP1134AR |
| Product Type | Capacitance Manometer (Unheated)Brooks Instrument |
| Full Scale Pressure | 1000 Torr (133.3 kPa)Brooks Instrument |
| Accuracy | ±0.25% of Reading (High Accuracy Option)Brooks Instrument |
| Repeatability | ±0.05% of Full ScaleBrooks Instrument |
| Zero Temperature Coefficient | ±0.01% FS/°C (Compensated)Brooks Instrument |
| Span Temperature Coefficient | ±0.01% FS/°C (Compensated)Brooks Instrument |
| Operating Temperature | +5°C to +60°CBrooks Instrument |
| Storage Temperature | -40°C to +70°CBrooks Instrument |
| Power Supply | 12–30 VDC |
| Power Consumption | Max 1.5 W @ 24 VDC |
| Output Signal | 0–10 VDC (Linear with Pressure) |
| Load Impedance | >10 kΩ |
| Response Time | ≤200 msBrooks Instrument |
| Wetted Materials | Inconel® (All-Welded Construction)Brooks Instrument |
| Process Connection | KF‑16 Flange (Code 2) |
| Electrical Connection | 9‑Pin Circular Connector |
| Dimensions | 52.3 mm (Dia.) × 52.58 mm (Length) |
| Weight | Approx. 120 gBrooks Instrument |
| Protection | IP40, EMI/RFI Filtered |
| Calibration | Digital Calibration, Factory CalibratedBrooks Instrument |
