1 PCS USED Schneider Electric ComPact NS800N 3P 800A #LYQ007
1 PCS USED Schneider Electric ComPact NS800N 3P 800A #LYQ007
| Parameter | Value |
|---|---|
| Product Type | Circuit Breaker (MCCB) |
| Model | ComPact NS800N 3P 800A (with MicroLogic 2.0 trip unit) |
| Number of Poles | 3P (3 poles, 3D) |
| Rated Current (In) | 800 A at 50 °C |
| Rated Operational Voltage (Ue) | 690 V AC, 50/60 Hz |
| Rated Insulation Voltage (Ui) | 800 V AC, 50/60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Network Type | AC |
| Network Frequency | 50/60 Hz |
| Utilisation Category | Category B |
| Suitability for Isolation | Yes (conforms to EN/IEC 60947-2) |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | 50 kA at 380/415 V AC
|
| Rated Service Breaking Capacity (Ics) | 50 kA at 380/415 V AC (Ics = Icu) |
| Trip Unit | MicroLogic 2.0 (Electronic) |
| Protection Functions | LI (Long-time & Instantaneous) |
| Long-time Pick-up Adjustment (Ir) | 0.4…1 × In (9 adjustable settings) |
| Mounting Mode | Fixed |
| Connection Pitch | 70 mm |
| Net Weight | 14 kg |
| Dimensions (W×H×D) | 327 mm × 210 mm × 147 mm |
| Ambient Operating Temperature | -25 °C to +70 °C |
| IK Rating | IK07 (conforms to EN 50102) |
| Standards | IEC 60947-1, IEC 60947-2 |
