1 PCS used WÖHRLE UGV-V 2402 module#LYQ007
1 PCS used WÖHRLE UGV-V 2402 module#LYQ007
| Parameter | Value |
|---|---|
| Model | UGV-V 2402 |
| Output Voltage | 24 V DC |
| Output Current | 2 A |
| Output Power | 48 W |
| Input Voltage Range | 85–264 V AC / 120–370 V DC |
| Input Frequency | 47–63 Hz |
| Efficiency (Typ.) | > 88 % |
| Ripple & Noise | < 120 mVpp |
| Hold-up Time | ≥ 16 ms at full load |
| Inrush Current | ≤ 50 A (cold start) |
| Overvoltage Protection | Auto shutdown at ~30 V DC |
| Overcurrent Protection | Hiccup mode, auto-recovery |
| Short Circuit Protection | Constant current limiting |
| Operating Temperature | -20 °C to +70 °C (derating above 50 °C) |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5–95 % RH, non-condensing |
| Isolation Voltage | 3 kV AC (input-output) |
| MTBF | > 500,000 hours (at 25 °C, full load) |
| Dimensions (W×H×D) | 45 × 125 × 100 mm |
| Weight | ~ 0.8 kg |
| Mounting | DIN rail (35 mm) |
| Protection Class | IP 20 |
| EMC Compliance | EN 55011, EN 50082-2 |
| Certifications | CE, UL 60950-1 |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
