1 PCS new ProMinent Beta® BT4B0708TTT0000UA101000 Solenoid-Driven Metering Pump #LYQ007
1 PCS new ProMinent Beta® BT4B0708TTT0000UA101000 Solenoid-Driven Metering Pump #LYQ007
| Parameter | Value |
|---|---|
| Model | BT4B0708TTT0000UA101000 |
| Series | Beta® 4 (BT4B) |
| Drive Type | Solenoid-driven diaphragm metering pump |
| Max Flow Rate | 7.1 L/h (1.89 GPH) |
| Max Operating Pressure | 7 bar (102 psi) |
| Stroke Rate | 18–180 strokes/min (10–100% in 10% steps) |
| Stroke Length | 0–100% continuous adjustment (recommended 30–100%) |
| Metering Accuracy | ±2% (under proper operating conditions) |
| Wetted Materials (TTT) | Carbon-filled PTFE (diaphragm, seals), PVDF (pump head) |
| Power Supply | 100–230 VAC, 50/60 Hz |
| Power Consumption | Approx. 16.5 W |
| Protection Class | IP65 |
| Ambient Temperature | –10 °C to +45 °C |
| Fluid Temperature | Max +20 °C |
| Connections | Inlet/Outlet: G 3/4" (DN10) hose connections |
| Weight | Approx. 3.02 kg |
| Dimensions (L×W×D) | 334 × 92 × 210 mm |
| Control Options | Manual; external pulse control; optional 4–20 mA |
| Features | Self-bleeding dosing head; LED status indicators; overload protection |
