1 PCS USED Inovance MD500T37GB AC Drive #LYQ007
1 PCS USED Inovance MD500T37GB AC Drive #LYQ007
| Item | Specification |
|---|---|
| Model | MD500T37GB |
| Product Type | High Performance Vector Control AC Drive |
| Rated Power | 37 kW |
| Input Voltage | 3PH 380–480 VAC, -15% ~ +10% |
| Input Frequency | 50/60 Hz, ±5% |
| Rated Input Current | 69 A |
| Power Capacity | 63 kVA |
| Output Voltage | 3PH 0–480 VAC (Proportional to input voltage) |
| Max. Output Frequency | 0–500 Hz |
| Rated Output Current | 75 A |
| Control Modes | Sensorless Vector Control (SVC), Feedback Vector Control (FVC), V/F Control |
| Starting Torque | 150% at 0.25 Hz (SVC); 180% at 0 Hz (FVC) |
| Speed Regulation Range | 1:100 (SVC); 1:1000 (FVC) |
| Speed Stability Accuracy | ±0.5% (SVC); ±0.02% (FVC) |
| Overload Capacity | 150% rated current for 60 seconds |
| Carrier Frequency | 0.8–12 kHz (Auto-adjustable) |
| Cooling Method | Forced Air Cooling |
| Protection Degree | IP20 |
| Ambient Temperature | -10°C ~ +50°C (Derating required above 40°C) |
| Built-in DC Reactor | Standard (H-class insulation)汇川技术 |
| Communication Interfaces | Modbus-RTU, CANopen, PROFIBUS-DP, PROFINET, EtherCAT (Optional) |
| Frame Size | T6 |
| Dimensions (H×W×D) | 400 × 250 × 220 mm |
| Weight | 17.5 kg |
| Certifications | CE, UL, CUL, RoHS汇川技术 |
| Manufacturer | Suzhou Inovance Technology Co., Ltd. |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2,We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
