Original Factory Precision Parameters (Model: 3.0205D)
|
Parameter Category
|
Parameter Name
|
Original Factory Precision Specification
|
|
Basic Information
|
Product Model
|
3.0205D; BAUMULLER Genuine Original Driver Board, 100% unused and unrefurbished genuine parts, consistent with BAUMULLER's official model coding standards. It belongs to high-precision industrial-grade digital driver board, designed for dedicated matching with BAUMULLER drive systems and motors, with fixed configuration and full compatibility with designated equipment models.
|
|
Manufacturer Standard
|
Manufactured by BAUMULLER Nurnberg GmbH (Genuine Original Factory); Compliant with ISO 9001 Quality Certification, CE, RoHS, IEC 61800-3, EN 61000 Industrial Standards; Conforms to BAUMULLER Internal Technical Standard and High-Precision Driver Board Manufacturing Norms, as well as EMC Standards EN 55011 (Emission) and EN 55022 (Immunity), meeting the precision calibration requirements of international industrial control standards.
|
|
|
Core Drive & Signal Parameters
|
Driver Type
|
Digital IGBT Driver Board; Integrated high-performance drive chip, supporting single/dual IGBT module drive; Adopting advanced signal conditioning and isolation technology, ensuring stable drive signal output; Compatible with N-channel IGBT modules, suitable for medium and low power drive scenarios, with built-in drive protection circuit to avoid IGBT damage.
|
|
Drive Voltage
|
DC ±15V (Main Drive Voltage), DC +5V (Control Circuit Voltage); The ±15V drive voltage is generated by the rectifier and voltage stabilization circuit on the board, and the +5V control voltage is generated by the 3846 chip and output from pin 2 after power-on, ensuring stable power supply for the drive and control circuits respectively; Voltage Stability: ±0.5% FS, ensuring consistent drive performance.
|
|
|
Switching Frequency
|
Nominal Switching Frequency: 2kHz ~ 16kHz (Adjustable); Default Frequency: 8kHz; Adaptable to different industrial application requirements for noise and efficiency control, supporting frequency adjustment through external signal or communication configuration.
|
|
|
Output Current
|
Peak Drive Current: ±5A; Continuous Drive Current: ±2A; Overcurrent Protection Threshold: 6A (Adjustable); Built-in overcurrent detection circuit, rapid response to current abnormalities to protect the driver board and IGBT module from damage.
|
|
|
Signal Response Time
|
Input Signal Response Time: ≤5μs; Output Signal Delay: ≤2μs; High-speed signal transmission, ensuring accurate synchronization of drive signals and control signals, improving the dynamic performance of the drive system.
|
|
|
Protection Functions
|
Integrated comprehensive protection: Overcurrent, Overvoltage, Undervoltage, Overheating, IGBT Short Circuit, Signal Loss Protection; Fault Alarm Output: NPN Open Collector (24V DC); Fault Memory: Stores up to 10 sets of recent fault records, convenient for maintenance and troubleshooting; Reverse polarity protection for power input and signal input/output, effectively preventing board damage.
|
|
|
Electrical Parameters
|
Power Supply
|
Input Voltage: DC 24V ±10% (Working Voltage); Input Voltage Range: DC 21.6V ~ 26.4V; Power Consumption: ≤10W (Standby), ≤30W (Working); Built-in overvoltage, undervoltage and reverse polarity protection, effectively preventing driver board damage caused by voltage abnormality; Auxiliary Power Supply: DC 12V ±5% (for signal isolation circuit), ensuring stable operation of the signal processing module.
|
|
Communication Protocol
|
Supports Industrial Fieldbus Protocols: CANopen, Modbus RTU, Profibus DP; Integrated communication interface for high-speed data transmission; Communication Baud Rate: Up to 1Mbps (CANopen/Modbus RTU), Up to 12Mbps (Profibus DP); Supports parameter reading/writing and drive status monitoring through communication, facilitating integration into industrial automation systems; Compatible with BAUMULLER BMA Service Software for parameter configuration and debugging.
|
|
|
Insulation & Anti-ESD
|
Insulation Resistance: ≥200MΩ (500V DC); Anti-Electrostatic Discharge (ESD): ±15kV (Air), ±8kV (Contact); Insulation Strength: 2.5kV AC (1 Minute); Effectively resisting static interference and voltage impact in industrial environments, ensuring stable operation; Anti-ESD performance complies with international industrial electrostatic protection standards.
|
|
|
Signal Isolation
|
All analog and digital signals adopt optical coupling isolation design, Isolation Voltage: ≥2.5kV AC; Signal Isolation Resistance: ≥100MΩ, effectively isolating external interference, ensuring accurate signal transmission and improving the stability of the control system; Isolation between power supply and signal circuit, further enhancing anti-interference capability.
|
|
|
Environmental & Physical Parameters
|
Operating Environment
|
Operating Temperature: 0℃ ~ 60℃ (32℉ ~ 140℉); Storage Temperature: -25℃ ~ 85℃ (-13℉ ~ 185℉); Operating Humidity: 10% ~ 95% RH (Non-Condensing); Storage Humidity: < 85% RH (Non-Condensing); Cooling Method: Natural Cooling + Forced Air Cooling (Optional); Suitable for most industrial indoor environments, avoiding use in strong corrosion, strong radiation and high-dust environments.
|
|
Physical Dimensions
|
Length: 135mm × Width: 90mm × Height: 25mm (±0.5mm); Weight: ≤0.6kg (Without Accessories); Housing Material: High-quality Aluminum Alloy, Good Heat Dissipation, Anti-corrosion, Anti-scratch; Installation Method: DIN Rail Installation / Flange Installation; Ergonomic design, easy to install and maintain, matching the installation dimensions of BAUMULLER standard driver modules.
|
|
|
Anti-Interference & Durability
|
Electromagnetic Compatibility (EMC): Complies with EN 55011 (Class A) Emission, EN 55022 (Class A) Immunity; Vibration Resistance: 10g (10Hz ~ 2000Hz); Shock Resistance: 50g (11ms); Service Life: ≥60,000 Hours (Under Rated Working Conditions); The anti-interference and durability performance meets BAUMULLER's strict product testing standards, suitable for long-term continuous operation in industrial scenarios; Surface adopts 3C3 anti-corrosion coating, adapting to harsh industrial environments.
|
