1 PCS new SICK TiM320-013000S02 #LYQ007
1 PCS new SICK TiM320-013000S02 #LYQ007
| Parameter | Value |
|---|---|
| Model | TiM320-013000S02 |
| Measurement Principle | HDDM+SICK |
| Application | IndoorSICK |
| Light Source | Infrared (850 nm)SICK |
| Laser Class | 1 (IEC 60825-1:2014, EN 60825-1:2014)SICK |
| Aperture Angle (Horizontal) | 270°SICK |
| Scanning Frequency | 15 HzSICK |
| Angular Resolution | 1°SICK |
| Working Range | 0.05 m ... 4 mSICK |
| Scanning Range (10% Remission) | 2 mSICK |
| Connection Type | Open wires (2.0 m)SICK |
| Supply Voltage | 9 V DC ... 28 V DCSICK |
| Power Consumption | Typ. 4 W; 16 W with 4 max. loaded digital outputsSICK |
| Output Current | ≤ 100 mASICK |
| Housing Color | Light blue (RAL 5012)SICK |
| Enclosure Rating | IP65 (IEC 60529:1989+AMD1:1999+AMD2:2013)SICK |
| Protection Class | III (IEC 61140:2016-1)SICK |
| Weight | 150 g (without connecting cables)SICK |
| Dimensions (L×W×H) | 60 mm × 60 mm × 79 mmSICK |
| Response Time | 1 scan: typ. 67 ms; 2 scans: ≤ 134 msSICK |
| Systematic Error | ± 40 mm (typical at 90% remission)SICK |
| Statistical Error | < 30 mm (typical at 90% remission)SICK |
| Integrated Application | Field evaluationSICK |
| Number of Field Sets | 16 field triples (48 fields)SICK |
| Digital Inputs | 4SICK |
| Digital Outputs | 3 (NPN) + 1 “Device Ready”SICK |
| Delay Time | 67 ms ... 30,000 ms (configurable)SICK |
| Ambient Operating Temp | –10 °C ... +50 °CSICK |
| Storage Temperature | –30 °C ... +70 °CSICK |
| Ambient Light Immunity | 80,000 lxSICK |
| Vibration Resistance | 10 Hz ... 1,000 Hz; 5 g (10–500 Hz)SICK |
| Shock Resistance | 50 g (11 ms), 25 g (6 ms), 50 g (3 ms)SICK |
| Interface | Micro USB (AUX, parameterization)SICK |
| Optical Indicators | 2 LEDs (ON, switching status)SICK |
| Object Remission | 4 % ... 1,000 % (reflectors)SICK |
| EMC | EN 61000-6-3 / EN 61000-6-2SICK |
