1 PCS NEW NPI45B10 74CC (Fairchild/ON Semiconductor) #LYQ007
1 PCS NEW NPI45B10 74CC (Fairchild/ON Semiconductor) #LYQ007
| Parameter | Symbol | Value | Unit | Condition |
|---|---|---|---|---|
| Manufacturer | — | Fairchild Semiconductor (ON Semiconductor) | — | — |
| Part Number | — | NPI45B10 74CC | — | — |
| Device Type | — | N-Channel Enhancement Mode Power MOSFET | — | — |
| Drain-Source Voltage | VDSS | 450 | V | — |
| Gate-Source Voltage | VGSS | ±30 | V | — |
| Continuous Drain Current (25°C) | ID | 10 | A | TC = 25°C |
| Pulsed Drain Current | IDM | 40 | A | tp ≤ 10μs |
| Drain-Source On-Resistance | RDS(on) | 0.45 | Ω | VGS = 10V, ID = 5A |
| Gate Threshold Voltage | VGS(th) | 2.0–4.0 | V | VDS = VGS, ID = 250μA |
| Forward Transconductance | gfs | 10 | S | VDS = 50V, ID = 5A |
| Input Capacitance | Ciss | 1800 | pF | VDS = 25V, VGS = 0V, f = 1MHz |
| Output Capacitance | Coss | 200 | pF | VDS = 25V, VGS = 0V, f = 1MHz |
| Reverse Transfer Capacitance | Crss | 50 | pF | VDS = 25V, VGS = 0V, f = 1MHz |
| Total Gate Charge | Qg | 80 | nC | VDS = 450V, VGS = 10V |
| Gate-Source Charge | Qgs | 15 | nC | VDS = 450V, VGS = 10V |
| Gate-Drain Charge | Qgd | 30 | nC | VDS = 450V, VGS = 10V |
| Turn-On Delay Time | td(on) | 30 | ns | VDD = 225V, ID = 5A, RG = 10Ω |
| Rise Time | tr | 80 | ns | VDD = 225V, ID = 5A, RG = 10Ω |
| Turn-Off Delay Time | td(off) | 120 | ns | VDD = 225V, ID = 5A, RG = 10Ω |
| Fall Time | tf | 60 | ns | VDD = 225V, ID = 5A, RG = 10Ω |
| Power Dissipation (25°C) | PD | 125 | W | TC = 25°C |
| Thermal Resistance (Junction to Case) | RθJC | 1.0 | °C/W | — |
| Operating Junction Temperature | TJ | -55 to +150 | °C | — |
| Package | — | TO-220 | — | — |
1 .Our company specializes in automation industrial control accessories. We have more than 100,000 products.
Including : frequency converter, servo driver, servo motor, data acquisition card, industrial camera, touch screen, circuit board, DCS module, soft starter, industrial computer,encoder... etc
2，We accept PayPal transaction. All products provided 60 days warranty. We can send the goods by fast express to all over world.
3. We can supply the product in brand new or used condition to meet your requirement.The picture and price show on our store is not real, before purchasing, please contact us to provide you with accurate quotation and real pictures.
4. If you can not find the product you need in our store, please contact us .we will check it for you.
