1 PCS NEW GESTRA NRGT 26-1S Capacitive Level Transmitter#LYQ007
1 PCS NEW GESTRA NRGT 26-1S Capacitive Level Transmitter#LYQ007
| Parameter | Value |
|---|---|
| Product Type | Capacitive Level Transmitter (Electrode Type) |
| Model | NRGT 26-1S |
| Service Pressure | PN 40, 32 bar g at 238 °C |
| Max. Operating Temperature (Medium) | 238 °C (460 °F) |
| Ambient Temperature | Max. 70 °C (158 °F) |
| Mechanical Connection | Flange DN 50, PN 40, DIN EN 1092-01 / DIN 2635 |
| Materials | - Screw-in body: 1.4571 (X6CrNiMoTi17-12-2)
|
| Measuring Principle | Capacitance measurement |
| Output Signal | 4–20 mA (level proportional), electrically isolated |
| Max. Load | 500 Ω |
| Supply Voltage | - 24 V AC/DC (±20% AC, +10%/–45% DC)
|
| Power Consumption | 3 VA (24 V DC) / 5 VA (24 V AC) |
| Sensitivity Ranges | - Range 1: Water ≥ 0.5 µS/cm
|
| Protection Class | IP 65 (DIN EN 60529) |
| Weight | approx. 8.0 kg |
| Fuse | Internal thermal fuse T = 102 °C |
| Type Approvals | GL, LR, RINA, BV, NKK, DNV, KR, ABS |
| Application | Boiler water level monitoring (marine & industrial) |
